These devices are specially designed for switching loads and signaling electrical conditions in a low-voltage switchgear. Depending on the contact layout, they are available as half or full modules. Devices with indicator lights have an LED that ensures optimal luminosity with very low consumption. For example, such devices are used to switch displays or other electrical components (such as fans, air conditioning systems).
| Property | Value |
| Number of poles: | 2 |
| Rated current: | 25 A |
| Rated voltage: | 400 V |
| Width in pitch units: | 0.5 |
| Switching function: | Off switch |
| With signal lamp: | yes |
| Type of voltage: | AC |
| Color of the cap: | gray |
| Light source: | LED |
| Protection class (IP): | IP20 |
| Min. rated voltage: | 24 V |
| Short-circuit strength (Icw): | 3 kA |
| Forced disconnection (according to DIN VDE 0113): | yes |
| Installation depth: | 68 mm |
| Max. lamp power: | 0.18 W |
| Number of contacts as normally open: | 2 |
Features
HAN
2CCA703111R0001
Manufacturer
HAB
E211X-25-20
GTIN
7612270938919
Color of the cap
Gray
Max. lamp power
0.18 W
Min. rated voltage
24 V
Rated voltage
400V
Rated current
25A
Width in pitch units
0.5
Installation depth
68 mm
Short circuit strength (Icw)
3kA
Lamps
LED
Number of contacts as normally open
2
With signal lamp
Yes
Number of poles
2
Switching function
Off switch
IP protection)
IP20
Voltage type
AC
