The complete meter panels of the DF series with three-point fastening are designed for installation in the Comfortline cabinet. The panels are pre-wired, which ensures quick and easy installation in the cabinet. The integrated main line branch terminals provide maximum space in the AAR, which can be used for up to three circuits if required. Furthermore, the cable routing, e.g. for the intelligent measuring system, has been optimized with new cable routing channels, so installation is now done in no time at all. The optional busbar connector can be used to cross-wire several panels as required. Applicable standards: DIN0603-1, DIN 43870-1, DIN 43870-2, DIN 43870-3, VDE-AR-N 4100
| Property | Value |
| Height: | 1050 mm |
| Width: | 750 mm |
| Width in modular units: | 36 |
| Design: | 1-storey |
| Connection compartment: | 300 mm |
| Number of meter spaces: | 3 |
| With wiring: | yes |
| With mounting plate: | no |
| Lower connection compartment: | with 5-pole busbar |
| Cover design: | closed with Knockout |
| Main switch rated current: | 63 A |
| Color: | grey |
| RAL number: | 7035 |
| Protection class (IP): | IP2XC |
Features
HAB
DF37Q3 7RE 6Z VV.m.ZK.
Manufacturer
HAN
2CPX054140R9999
GTIN
4011617541400
Connection room
300 mm
Number of meter slots
3
Version
1-storey
Cover design
Closed with pre-stamping
Width
750 mm
Width in pitch units
36
Color
Main switch rated current
63 A
Height
1050 mm
With mounting plate
No
With wiring
Yes
RAL number
7035
IP protection)
IP2XC
Lower connection compartment
With busbar 5-pole
