Presence detector for daylight-dependent lighting control, 1 - 10 V interface for controlling analogue, dimmable electronic ballasts, additional switching channel for the following function:, cut-off (complete electronic ballast shutdown to avoid standby losses), orientation light function, manual switching and dimming via button possible, version as master device, extension of the detection area with slave devices possible, additional functions can be set via optional remote control, relay with tungsten pre-contact, optimized for LED loads, avoidance of standby losses of the lighting system according to EnEV DIN V 18599-4
| Property | Value |
| Height: | 65.0 mm |
| Version: | Presence detector |
| Color: | white |
| Nominal voltage: | 240 V |
| RAL number (similar): | 9010.0 |
| Material: | Plastic |
| Mounting type: | Flush-mounted |
| Response brightness: | 50 to 2000 lx |
| Protection class (IP): | IP20 |
| Max. Switching capacity: | 2300 W |
| Voltage type: | AC |
| Max. range to one side: | 5 m |
| Suitable for wall mounting: | no |
| Min. duty cycle: | 60 s |
| Max. duty cycle: | 30 min |
| Creep-by protection/rear field monitoring: | yes |
| Temperature: | -25 to 50 °C |
| Adjustable response brightness: | yes |
| Adjustable response sensitivity: | yes |
| Max. Presence area: | 12.0 m² |
| Max. frontal range: | 6 m |
| Max. Inrush current: | 165 A |
| Sensor type: | passive infrared |
| Optimal mounting height: | 2.5 m |
| Surface finish: | matt |
| Surface: | untreated |
| Material quality: | other |
| Detection field diameter on floor: | 7 m |
| Control current: | 2 mA |
| Number of switching zones: | 78.0 |
| Frequency: | 50 to 60 Hz |
| Halogen-free: | yes |
| Constant light control: | yes |
| HVAC control: | no |
| Forced shutdown: | no |
| Animal corridor: | no |
| Networkable: | no |
| Staircase monitoring: | yes |
| Bypass switch: | no |
| Suitable for wireless transmission: | no |
| Remote control: | yes |
| With Signal unit: | no |
| Alarm function: | no |
| Teach function for response brightness: | yes |
| Dimming function with dimming insert: | no |
| Transparent: | no |
| With remote control: | no |
| Suitable for C load: | no |
| With DALI interface: | no |
| Extension input: | yes |
| Suitable for ceiling mounting: | yes |
| Antibacterial Treatment: | no |
| Impact resistance: | IK05 |
| Diameter: | 98.0 mm |
Features
Bridging switch
No
With signal unit
No
Number of switching zones
78.0
Response brightness
50 to 2000 lx
Forced shutdown
No
Max. inrush current
165 A
Max. presence range
12.0 m²
HAB
PD2-Master, dimming version, flush-mounted
Manufacturer
HAN
92157
GTIN
4007529921577
Dimming function with dimming insert
No
Alarm function
No
Response sensitivity adjustable
Yes
Response brightness adjustable
Yes
Antibacterial treatment
No
Version
Surface finish
Frosted
Diameter
98.0 mm
Detection field diameter on floor
7m
Color
Remote controllable
Yes
Frequency
50 to 60 Hz
Suitable for C-load
No
Suitable for ceiling mounting
Yes
Suitable for wall mounting
No
Suitable for wireless transmission
No
HVAC control
No
Halogen free
Yes
Height
65.0 mm
Constant light control
Yes
Max. duty cycle
30 min
Max. range frontal
6m
Max. range to one side
5 m
Max. switching capacity
2300W
Min. duty cycle
60s
With DALI interface
No
With remote
No
Mounting type
Flush-mounted
Extension input
Yes
Nominal voltage
Surface
Untreated
Optimal mounting height
2.5m
RAL number (similar)
9010.0
Impact resistance
IK05
IP protection)
IP20
Sensor type
Voltage type
AC
Teach function for response brightness
Yes
Temperature
-25 to 50 °C
Animal corridor
No
Transparent
No
Staircase monitoring
Yes
Creep protection/rear field monitoring
Yes
Networkable
No
Material
Plastic
Material quality
Other
