LED pendant ring light, direct, DALI dimmable, structural silver, round. Pendant mounting, ceiling mounting Mounting type: pendant mounting, Installation location: ceiling mounting, Material: aluminum / steel / plastic, Protection class on the room side: according to DIN EN 60529: IP40, Protection class: (EN 61140) I, Voltage: 230V AC 50Hz, Power: 75W, Number of lamps / sockets: 1.0 pcs, Luminous flux: 7,470 lm, Color temperature: 3,000 K, Light color: white, Beam angle: 110°, With control gear: Yes, Type of dimming: DALI.
| Property | Value |
| Max. System power: | 75 W |
| Rated luminous flux according to IEC 62722-2-1: | 7470 lm |
| Color temperature: | 3000 K |
| Diameter: | 1200 mm |
| Suitable for number of lamps: | 1 |
| Height/depth: | 100 mm |
| Protection rating (IP): | IP20 |
| Protection class: | I |
| Pendant length: | 5000 mm |
| Housing material: | Aluminum |
| With light source: | yes |
| With control gear: | yes |
| Nominal voltage: | 240 V |
| Suspension included: | yes |
| Cover material: | Opal plastic |
| Light source: | LED not replaceable |
| Housing color: | Silver |
| Design of the grid: | without |
| Reflector: | without |
| Suitable for light strip configuration: | no |
| Light distribution: | symmetrical |
| Light emission: | direct |
| Color rendering index CRI: | 80-89 |
| Suitable for emergency lighting: | no |
| Light color: | white |
| Voltage type: | AC |
| Dimming 0-10 V: | no |
| Dimming 1-10 V: | no |
| Dimming DALI: | yes |
| Dimming DMX: | no |
| Dimming programmable: | no |
| Dimming DSI: | no |
| Dimming RF: | no |
| Dimming potentiometer (device integrated): | no |
| Dimming GPRS: | no |
| Dimming LineSwitch: | no |
| Dimming manufacturer-specific: | no |
| Dimming mains voltage modulation: | no |
| Dimming trailing edge: | no |
| Dimming Phase control: | no |
| Dimming Sine Wave Reduction: | no |
| Dimming Touch and Dim: | no |
| Dimming Zigbee: | no |
| Dimming with push button: | no |
| Without dimming function: | no |
| Suitable for lamp power: | 75 W |
| Rated service life L70/B50 at 25 °C: | 276000 h |
Features
HAB
13633163 3000K ss 1200mm
Manufacturer
HAN
13633163
GTIN
4251433941354
Suspension included
Yes
Execution of the grid
Without
Rated lifetime L70/B50 at 25 °C
276000 hours
Rated luminous flux according to IEC 62722-2-1
7470lm
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
Yes
Dimming DMX
No
Dimming DSI
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming mains voltage modulation
No
Dimming trailing edge
No
Dimming phase control
No
Dimming potentiometer (integrated)
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming manufacturer-specific
No
Dimming with push button
No
Dimming programmable
No
Diameter
1200 mm
Color temperature
3000K
Color rendering index CRI
80-89
Suitable for lamp power
75W
Suitable for number of lamps
1
Suitable for light strip configuration
No
Suitable for emergency lighting
No
Housing color
Silver
Height/Depth
100 mm
Lamps
LED not replaceable
Light emission
Direct
Light color
White
Light distribution
Symmetrical
Max. system performance
75W
With operating device
Yes
With light source
Yes
Nominal voltage
240V
Without dimming function
No
Pendulum length
5000 mm
Reflector
Without
IP protection)
IP20
Protection class
I
Voltage type
AC
Cover material
Plastic opal
Housing material
Aluminum
