LED flex board, 100 mm, CRI > 90, 14.4 W / m, IP67, LED white light, 2,700K, CRI > 90 LED flex board for decorative, technical and efficient lighting of light coves, linear applications and backlighting, basic or general lighting of rooms, architectural applications and for areas in which high illumination is desired, such as indirect or direct lighting, light ceilings, restaurant lighting and much more. Length: 100.0 mm Lamp power per meter: 14.4 W / m, luminous flux per meter: 1050.0 lm / m, protection class on the room side: IP67, protection class: III, voltage: 24V DC, beam angle: 120.0 °, 60 LEDs per meter, chip spacing (short pitch): 16.7 mm. For individual use, the LED flex board can be shortened every 100 mm. If the LED flex board is shortened, the IP protection must be restored on site. The maximum system length of 5,000 mm must not be exceeded with one feed.
| Property | Value |
| Lamp power per meter: | 14.4 W |
| Length of individual sections: | 100 mm |
| Number of lamps per meter: | 60 |
| Smallest bending radius: | 40 mm |
| Width: | 12.7 mm |
| Length: | 100 mm |
| Beam angle: | 120 ° |
| Design: | Band |
| Color temperature: | 2700 K |
| Light source: | LED not replaceable |
| Protection class (IP): | IP67 |
| Self-adhesive: | yes |
| Voltage type: | DC |
| Luminous flux per meter: | 1050 lm |
| Lamp voltage: | 24 V |
| Operating device: | LED operating device voltage controlled |
| Protection class: | III |
| Light color: | white |
| Color rendering index CRI: | 90-100 |
| Height/Depth: | 5 mm |
| Number of poles: | 2 |
