Description
3-wire DualTech motion detector with passive infrared and ultrasonic detection as well as brightness sensor. Can be used as a conventional motion detector (automatic ON - automatic OFF) or as a Green Switch (ON - automatic OFF using the button on the device). Settings are made using the remote control Art. BMSO4003 or BMSO4005. 230VAC - neutral conductor required - relay output up to 8.5A max. - 2 modules, color: anthracite
| Property | Value |
| Design: | Presence detector |
| Color: | anthracite |
| Nominal voltage: | 230 V |
| Material: | Plastic |
| Mounting type: | Flush-mounted |
| Response brightness: | 5 to 1275 lx |
| Protection class (IP): | IP20 |
| Max. switching capacity: | 2000 W |
| Type of voltage: | AC |
| Max. Range to one side: | 8 m |
| Min. duty cycle: | 5 s |
| Creep-under protection/rear field monitoring: | no |
| Temperature: | -5 to 45 °C |
| Adjustable response brightness: | yes |
| Max. Frontal range: | 8 m |
| Optimal installation height: | 1.2 m |
| Surface finish: | matt |
| Surface: | other |
| Material quality: | thermoplastic |
| Detection field diameter on floor: | 3 m |
| Horizontal detection angle: | 180 ° |
| Frequency: | 50 to 60 Hz |
| Halogen-free: | no |
| Constant light control: | no |
| HVAC control: | no |
| Forced shutdown: | yes |
| Animal corridor: | no |
| Networkable: | no |
| Staircase monitoring: | no |
| Bypass switch: | no |
| Suitable for wireless transmission: | no |
| Remote controllable: | yes |
| With signal unit: | no |
| Alarm function: | no |
| Teach function for response brightness: | no |
| Dimming function with dimming insert: | no |
| Transparent: | no |
| Extension input: | no |
| Antibacterial treatment: | no |
Features
Bridging switch
No
With signal unit
No
Response brightness
5 to 1275 lx
Forced shutdown
Yes
Manufacturer
HAN
L4433N
GTIN
8005543441947
Dimming function with dimming insert
No
Alarm function
No
Response brightness adjustable
Yes
Antibacterial treatment
No
Version
Presence detector
Surface finish
Frosted
Detection field diameter on floor
3m
Detection angle horizontal
180°
Color
Remote controllable
Yes
Frequency
50 to 60 Hz
Suitable for wireless transmission
No
HVAC control
No
Halogen free
No
Constant light control
No
Max. range frontal
8m
Max. range to one side
8m
Max. switching capacity
2000W
Min. duty cycle
5s
Mounting type
Flush-mounted
Extension input
No
Nominal voltage
230V
Surface
Other
Optimal mounting height
1.2m
IP protection)
IP20
Voltage type
AC
Teach function for response brightness
No
Temperature
-5 to 45 °C
Animal corridor
No
Transparent
No
Staircase monitoring
No
Creep protection/rear field monitoring
No
Networkable
No
Material
Plastic
Material quality
Thermoplastic
