Brightness, temperature switch, ABB i-bus KNX, physical sensors, weather control center/station, 3-way brightness, temperature switch For recording and sending the brightness and temperature. Threshold switch for controlling switching, dimming and blind actuators depending on the ambient brightness and/or temperature. With blocking object for deactivating one or more threshold switches. The bus connection is made via a bus connection terminal. Connections: KNX line: Bus connection terminal Inputs: 2 Brightness limit: 1 lux - 100,000 lux Protection class (device): IP 54 Temperature range (device): -25 °C to 55 °C Dimensions (H x W x D): 110 mm x 72 mm x 54 mm
| Property | Value |
| Mounting type: | Surface-mounted |
| Protection class (IP): | IP54 |
| Design: | Multiple sensor |
| KNX bus system: | yes |
| Radio bus system: | no |
| Color: | gray |
| LON bus system: | no |
| Powernet bus system: | no |
| With bus connection: | yes |
| With DCF77: | no |
| Acoustic signal: | no |
| With heating: | no |
| Analog input: | no |
| Weather station: | yes |
| Bus system KNX radio: | no |
| Bidirectional radio: | no |
Features
Way
HAB
6146/10
Manufacturer
HAN
2CKA006146A0022
GTIN
4011395085066
Version
Bus system radio bus
No
KNX bus system
Yes
KNX radio bus system
No
LON bus system
No
Powernet bus system
No
Color
Radio bidirectional
No
Suitable for outdoor use
No
With bus connection
Yes
Mounting type
Surface-mounted
IP protection)
IP54
