Mounting type: Wall mounting/ceiling mounting Function: Escape route marking Suitable for type of marking: Insert sheet/plate Type of marking: one-sided/two-sided With pictogram: yes Monitoring device: automatic self-test Switching type: Maintained switching/standby switching With remote switch connection: yes Feed: decentralized (single battery) Battery type: lithium-ion Light source: LED not replaceable With light source: yes Suitable for number of light sources: 1 Socket: without Number of light heads: 16 Housing material: plastic Housing color: white Cover material: transparent plastic Voltage type: AC Nominal voltage: 230 V Operating device: not required Light distributor: diffuser lens/optics/panel Energy efficiency class of the permanently installed light source: A++, A+, A (LED) Rated service life L70/B10 at 25 °C: 54000 h Protection class (IP): IP43 Impact resistance: IK07
| Property | Value |
| Housing color: | white |
| Protection rating (IP): | IP43 |
| Protection class: | II |
| Voltage type: | AC |
| Nominal voltage: | 220 to 240 V |
| Detection range: | 20 m |
| Color temperature: | 6500 K |
| Length: | 228 mm |
| Width: | 120 mm |
| Height/Depth: | 34 mm |
| Max. System performance: | 2 W |
| Battery type: | Lithium-ion |
| Nominal operating time: | 1 to 8 h |
| Rated luminous flux according to IEC 62722-2-1: | 60 lm |
| Light source: | LED not replaceable |
| Impact resistance: | IK07 |
| Socket: | without |
| With remote switch connection: | no |
| Cover material: | Transparent plastic |
| Installation width: | 130 mm |
| With light source: | yes |
| Installation length: | 245 mm |
| Monitoring device: | automatic self-test |
| Housing material: | plastic |
| Type of marking: | one-/two-sided |
| Suitable for type of marking: | Insert sheet/plate |
| Feed: | decentralized (single battery) |
| With pictogram: | yes |
| Suitable for number of light sources: | 1 |
| Number of Lamp heads: | 1 |
| Light distributor: | Diffuser lens/optics/panel |
| Luminaire with limited surface temperature D-mark according to EN 60598-2-24: | no |
| Power factor: | 0.4 |
| Installation height/depth: | 50 mm |
| Number of poles: | 3 |
| Conductor cross-section: | 2.5 mm² |
| Connection type: | Plug connection |
