Thin-bed heating mat with a connecting cable and suitable sensor protection tube DN10 with red cap. The self-adhesive thin-bed heating mat with a connecting cable is ready for installation and was specially developed for installation in leveling compound or flexible adhesive directly underneath the floor covering. Due to the low installation height of only 3.2 mm, it is ideal for renovating and modernizing bathrooms, showers, kitchens, etc. This underfloor heating system is particularly suitable for subsequent installation in angled and/or large rooms, as there is no need to return the second connection. The heating cable with additional protective braiding for use with the residual current circuit breaker is attached to a plastic net. The length of the connecting cables is 4.0 m. PTC thermistor: 1 x 4m, 1.0 mm², voltage: 230 V, nominal limit temperature: 120°C, specific heating output: 100 W/m², length load: 11W, insulation: PVDF / FEP, resistance tolerance: +10% / -5%, minimum installation temperature: 5°C, smallest bending radius: 6 x dA, calculation width 50 cm, delivery width: 48 cm, mat height: 3.2 mm, protection class: IPX7, approval: EN 60335-2-96, area 4.0 m², 0.5 x 8.0 m
| Property | Value |
| Length: | 8000 mm |
| Width: | 500 mm |
| Thickness: | 3.5 mm |
| Connection power: | 400 W |
| Area: | 4 m² |
| Power: | 100 W/m² |
| With carrier mat: | yes |
| Heating conductor load: | 11 W/m |
| Fixing of the heating conductor: | glued |
| Number of PTC thermistor: | 1 |
| Length of PTC thermistor: | 4000 mm |
| Suitable as roof heating: | no |
| Suitable as open-air heating: | no |
| Self-adhesive: | yes |
| Design: | Heating cable |
| Connection voltage: | 230 V |
| Resistance: | 132 Ohm |
