UV-stable diffuser and housing Thanks to the integrated pressure equalization valve, it is suitable for outdoor use Chemical-resistant special diffuser made of ChemRST material Suitable for agricultural operations Housing made of impact-resistant polycarbonate Impact resistance IK06 Suitable for central battery IP66 / IP69 D-validated DLG Validated Distance between the two mounting brackets adjustable (700-980mm)
| Property | Value |
| Max. System power: | 54 W |
| Rated luminous flux according to IEC 62722-2-1: | 7170 lm |
| Length: | 1455 mm |
| Width: | 90 mm |
| Height/depth: | 99 mm |
| Protection rating (IP): | IP66 |
| Protection class: | I |
| Luminaire with limited surface temperature 'D-mark': | no |
| Nominal voltage: | 100 to 240 V |
| Housing color: | gray |
| Color temperature: | 4000 K |
| Impact resistance: | IK06 |
| Color rendering index CRI: | 80-89 |
| Suitable for ceiling mounting: | yes |
| Rated service life L80/B10 at 25 °C: | 50000 h |
| Suitable for wall mounting: | no |
| Voltage type: | AC |
| With motion detector: | no |
| Beam angle: | extremely wide beam>80° |
| With light source: | no |
| Light source: | LED not replaceable |
| Rated ambient temperature according to IEC62722-2-1: | -25 to 45 °C |
| With control gear: | no |
| Without dimming function: | yes |
| With light sensor: | no |
| Suitable for recessed mounting: | no |
| Suitable for computer workstations according to EN 12464-1: | no |
| Suitable for strip light configuration: | no |
| Suitable for pendant suspension: | no |
| Suitable for surface mounting: | yes |
| Suitable for emergency lighting: | no |
| Covering of the luminaire with thermal insulation material possible: | no |
| Dimming DMX: | no |
| Dimming DSI: | no |
| With air slots: | no |
| Dimming LineSwitch: | no |
| Dimming Potentiometer (device integrated): | no |
| Dimming 0-10 V: | no |
| Dimming GPRS: | no |
| Dimming 1-10 V: | no |
| Dimming manufacturer-specific: | no |
| Dimming DALI: | no |
| Dimming mains voltage modulation: | no |
| Dimming trailing edge: | no |
| Dimming leading edge: | no |
| Dimming programmable: | no |
| Dimming RF: | no |
| Dimming Sine Wave Reduction: | no |
| Dimming Touch and Dim: | no |
| Dimming Zigbee: | no |
| Dimming with push button: | no |
| Dimming depending on operating device: | no |
| Power factor: | 0.95 |
Features
Manufacturer
HAN
4777-040120
GTIN
4260629143076
Covering the luminaire with thermal insulation material possible
No
Rated lifetime L80/B10 at 25 °C
50000 hours
Rated luminous flux according to IEC 62722-2-1
7170lm
Rated ambient temperature according to IEC62722-2-1
-25 to 45 °C
Suitable for computer workstations according to EN 12464-1
No
Width
90 mm
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming mains voltage modulation
No
Dimming trailing edge
No
Dimming phase control
No
Dimming potentiometer (integrated)
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming depends on the control gear
No
Dimming manufacturer-specific
No
Dimming with push button
No
Dimming programmable
No
Color temperature
4000K
Color rendering index CRI
80-89
Suitable for surface mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for flush mounting
No
Suitable for light strip configuration
No
Suitable for emergency lighting
No
Suitable for pendulum suspension
No
Suitable for wall mounting
No
Housing color
Gray
Height/Depth
99 mm
Power factor
0.95
Luminaire with limited surface temperature D-mark
No
Lamps
LED not replaceable
Length
1455 mm
Max. system performance
54W
With operating device
No
With motion detector
No
With light source
No
With light sensor
No
With air slots
No
Nominal voltage
100 to 240 V
Without dimming function
Yes
Impact resistance
IK06
IP protection)
IP66
Protection class
I
Voltage type
AC
