Transformer circuit breaker, IEC/EN 60947,0660, overload release = 10 - 16 A, max. 280 A, rated continuous current Iu = 16 A, design of the actuating element: rotary knob, number of poles: 3, protection class: device = IP20, connection terminals = IP20, ambient temperature: storage = - 40 - 80 °C, open = -25 - +55 °C, energy feed direction as required
| Property | Value |
| Rated continuous current Iu: | 16 A |
| Connection type main circuit: | Spring-loaded connection |
| Number of poles: | 3 |
| Device design: | Built-in device, fixed installation technology |
| Position of connection for main circuit: | other |
| Protection class (IP): | IP20 |
| Overload release current setting: | 16 A |
| Setting range of the instantaneous short-circuit release: | 358 A |
| Rated voltage: | 690 V |
| Rated short-circuit breaking current Icu at 400 V, 50 Hz: | 50 kA |
| Suitable for DIN rail mounting: | no |
| Design of the actuating element: | Rotary knob |
| Integrated earth fault protection: | no |
| Motor drive integrated: | no |
| Motor drive optional: | no |
| With trip detector: | no |
| Complete device with protection unit: | no |
| DIN rail mounting optional: | yes |
Features
HAB
PKZM0-16-T-PI
Manufacturer
HAN
199174
GTIN
4015081972586
Connection type main circuit
Spring-loaded connection
Design of the actuating element
Rotary knob
Rated continuous current Iu
16A
Rated ultimate short-circuit breaking current Icu at 400 V, 50 Hz
50kA
Rated voltage
690V
Setting range of the instantaneous short-circuit release
358 A
Suitable for DIN rail mounting
No
Device type
Built-in device Fixed installation technology
DIN rail mounting optional
Yes
Integrated earth fault protection
No
Complete device with protection unit
No
With trip detector
No
Motor drive integrated
No
Motor drive optional
No
Number of poles
3
Position of the connection for main circuit
Other
IP protection)
IP20
Overload release current setting
16A
