Power contactor for 4-pole consumers, power contactors up to 200 A, 4-pole, utilization category: AC-1: non-inductive or slightly inductive load, resistance furnaces, AC-3/AC-3e: squirrel cage motors: starting, switching off during operation, connection technology: push-in terminals, number of poles: 4-pole, 380 V 400 V: Ie= 12 A, conventional thermal current, 3-pole, 50 - 60 Hz open at 40 °C: Ith = Ie= 22 A, encapsulated: Ith= 18 A, conventional thermal current 1-pole open: Ith= 60 A, encapsulated: Ith= 54 A, 220 V 230 V: P= 3.5 kW, 380 V 400 V: P= 5.5 kW, 660 V 690 V: P= 6.5 kW, Switching elements according to EN 50012., Integrated varistor protective circuit., Current type AC/DC: DC operation
| Property | Value |
| Number of normally open contacts as main contacts: | 4 |
| Rated operating power at AC-3, 400 V: | 5.5 kW |
| Rated operating power at AC-4, 400 V: | 4.5 kW |
| Rated operating current Ie at AC-1, 400 V: | 22 A |
| Rated operating current Ie at AC-3, 400 V: | 12 A |
| Rated operating current Ie at AC-4, 400 V: | 10 A |
| Voltage type for Actuation: | DC |
| Rated control supply voltage Us at DC: | 24 V |
| Connection type main circuit: | Spring-loaded connection |
| Suitable for series installation: | no |
Features
HAB
DILMP20 (24VDC) -PI
Manufacturer
HAN
199263
GTIN
4015081973477
Connection type main circuit
Spring-loaded connection
Number of normally open contacts as main contacts
4
Rated operational power at AC-3, 400 V
5.5kW
Rated operational power at AC-4, 400 V
4.5kW
Rated operational current Ie at AC-1, 400 V
22A
Rated operational current Ie at AC-3, 400 V
12A
Rated operational current Ie at AC-4, 400 V
10A
Rated control supply voltage Us at DC
24V
Suitable for series installation
No
Voltage type for actuation
DC
