FAZ circuit breaker, 2-pole, tripping characteristic: K, rated current In: 40 A, switching devices for industrial applications and high-end commercial buildings
| Property | Value |
| Tripping characteristic: | K |
| Rated current: | 40 A |
| Rated voltage: | 400 V |
| Type of voltage: | AC |
| Frequency: | 50 to 60 Hz |
| Width in pitch units: | 2 |
| Number of poles (total): | 2 |
| Energy limitation class: | 3 |
| Additional equipment possible: | yes |
| Overvoltage category: | 3 |
| Installation depth: | 70.5 mm |
| Protection class (IP): | IP20 |
| Rated switching capacity Icu according to IEC 60947-2 at 230 V: | 10 kA |
| Rated switching capacity Icu according to IEC 60947-2 at 400 V: | 10 kA |
| Pollution degree: | 2 |
| Switching neutral conductor: | no |
| Number of protected poles: | 2 |
| Rated insulation voltage Ui: | 440 V |
| Rated impulse withstand voltage Uimp: | 4 kV |
| Ambient temperature during operation: | -25 to 75 °C |
| Connectable conductor cross-section, stranded: | 1 to 25 mm² |
| Connectable conductor cross-section, solid: | 1 to 25 mm² |
Features
HAB
FAZ-K40/2
Manufacturer
HAN
278802
GTIN
4015082788025
Connectable conductor cross-section solid
1 to 25 mm²
Connectable conductor cross-section stranded
1 to 25 mm²
Number of protected poles
2
Trigger characteristics
K
Rated insulation voltage Ui
440V
Rated switching capacity Icu according to IEC 60947-2 at 230 V
10kA
Rated switching capacity Icu according to IEC 60947-2 at 400 V
10kA
Rated voltage
400V
Rated impulse withstand voltage Uimp
4kV
Rated current
40A
Width in pitch units
2
Installation depth
70.5 mm
Energy limitation class
3
Frequency
50 to 60 Hz
Switching neutral conductor
No
Number of poles (total)
2
IP protection)
IP20
Voltage type
AC
Ambient temperature during operation
-25 to 75 °C
Degree of contamination
2
Additional equipment possible
Yes
Overvoltage category
3
