Circuit breaker FAZ-T, 3-pole+N, tripping characteristic: B, rated current In: 3 A, switching devices for industrial applications and high-end commercial buildings
| Property | Value |
| Tripping characteristic: | B |
| Rated current: | 3 A |
| Rated voltage: | 230 V |
| Type of voltage: | AC |
| Frequency: | 50 to 60 Hz |
| Width in pitch units: | 4 |
| Number of poles (total): | 4 |
| Energy limitation class: | 3 |
| Additional equipment possible: | yes |
| Overvoltage category: | 3 |
| Installation depth: | 70.5 mm |
| Protection class (IP): | IP20 |
| Rated switching capacity Icn according to EN 60898 at 230 V: | 15 kA |
| Rated switching capacity Icu according to IEC 60947-2 at 230 V: | 25 kA |
| Rated switching capacity Icu according to IEC 60947-2 at 400 V: | 25 kA |
| Rated switching capacity Icn according to EN 60898 at 400 V: | 15 kA |
| Pollution level: | 2 |
| Switching neutral conductor: | yes |
| Number of protected poles: | 3 |
| Rated insulation voltage Ui: | 440 V |
| Rated impulse withstand voltage Uimp: | 4 kV |
| Ambient temperature during operation: | -25 to 75 °C |
| Connectable conductor cross-section, stranded: | 1 to 25 mm² |
| Connectable conductor cross-section, solid: | 1 to 25 mm² |
Features
HAB
FAZT-B3/3N
Manufacturer
HAN
241070
GTIN
4015082410704
Connectable conductor cross-section solid
1 to 25 mm²
Connectable conductor cross-section stranded
1 to 25 mm²
Number of protected poles
3
Trigger characteristics
B
Rated insulation voltage Ui
440V
Rated switching capacity Icn according to EN 60898 at 230 V
15kA
Rated switching capacity Icn according to EN 60898 at 400 V
15kA
Rated switching capacity Icu according to IEC 60947-2 at 230 V
25kA
Rated switching capacity Icu according to IEC 60947-2 at 400 V
25kA
Rated voltage
230V
Rated impulse withstand voltage Uimp
4kV
Rated current
3 A
Width in pitch units
4
Installation depth
70.5 mm
Energy limitation class
3
Frequency
50 to 60 Hz
Switching neutral conductor
Yes
Number of poles (total)
4
IP protection)
IP20
Voltage type
AC
Ambient temperature during operation
-25 to 75 °C
Degree of contamination
2
Additional equipment possible
Yes
Overvoltage category
3
