ON-OFF switch, product range: control switches, type reference: TM, with black knob and front plate, contacts: 1, protection class: front IP65, design: flush-mounted, switching angle: 90 °, switching behavior: latching, with 0 position, front plate: 0-1, rated operating power AC-23A, 50 - 60 Hz 400 V: P = 3 kW, rated continuous current: Iu = 10 A, 1 unit(s), standards and regulations: IEC/EN 60947,0660, CSA, UL, control switch according to IEC/EN 60947-5-1, auxiliary switch according to IEC/EN 60947-5-1
| Property | Value |
| Number of poles: | 1 |
| Rated operating power at AC-23, 400 V: | 3 kW |
| Rated continuous current Iu: | 10 A |
| Max. Rated operating voltage Ue at AC: | 500 V |
| Version as EMERGENCY STOP device: | no |
| Protection class (IP), front: | IP65 |
| Connection type main circuit: | screw connection |
| Device design: | Built-in device, fixed installation technology |
| Design of the actuating element: | short rotary handle |
| Suitable for floor mounting: | no |
| Integrated motor drive: | no |
| Suitable for front mounting 4-hole: | yes |
| Version as maintenance/repair switch: | no |
| Voltage release optional: | no |
| Suitable for front mounting central: | no |
| Suitable for intermediate installation: | no |
| Suitable for distribution board installation: | no |
| Version as main switch: | no |
| Version as safety switch: | no |
| Motor drive optional: | no |
| Lockable: | no |
| Version as Reversing switch: | no |
| Color of the actuating element: | black |
| Rated operating voltage: | 500 V |
| Number of switches: | 1 |
| Protection class (NEMA): | 12 |
Features
HAB
TM-1-8290/E
Manufacturer
HAN
070131
GTIN
4015080701316
Connection type main circuit
Screw connection
Number of switches
1
Designed as main switch
No
Designed as an EMERGENCY STOP device
No
Designed as a safety switch
No
Designed as a maintenance/repair switch
No
Version as reversing switch
No
Design of the actuating element
Short twist grip
Rated operational power at AC-23, 400 V
3kW
Rated operating voltage
500V
Rated continuous current Iu
10A
Color of the actuator
Black
Suitable for floor mounting
No
Suitable for front mounting 4-hole
Yes
Suitable for front mounting Central
No
Suitable for distribution board installation
No
Suitable for intermediate construction
No
Device type
Built-in device Fixed installation technology
Max. rated operating voltage Ue at AC
500V
Motor drive integrated
No
Motor drive optional
No
Number of poles
1
Protection class (IP), front
IP65
Protection class (NEMA)
12
Voltage release optional
No
Lockable
No
