Impulse switch, control voltage 240V 50Hz, function: 1 NO contact and 1 NC contact, rated current at 250V AC according to IEC/EN 60669-2-2: 16A, cap installation dimension 45mm, installation width 1TE (17.5mm), DIN rail mounting, terminal cross-section 0.5-10 qmm single and multi-wire / 0.5-6 qmm fine-wire with wire end ferrule
| Property | Value |
| Width in modular spacing: | 1 |
| Rated switching current: | 16 A |
| Control voltage 1: | 240 V |
| Control voltage type 1: | AC |
| Control voltage type 2: | AC |
| Installation depth: | 60 mm |
| Function: | mechanical switch |
| Mounting type: | DIN rail |
| Frequency of control voltage 1: | 50 Hz |
| Type of supply voltage: | AC |
| Supply voltage: | 24 to 240 V |
| Max. incandescent lamp load: | 2024 W |
| Max. fluorescent lamp load: | 2500 VA |
| Max. fluorescent lamp load (duo circuit): | 2500 VA |
| Max. fluorescent lamp load (parallel compensated): | 2500 VA |
| Max. Switching current (cos phi = 0.6): | 24 A |
| Number of contacts as normally open: | 1 |
| Number of contacts as normally closed: | 1 |
Features
Type of voltage of the supply voltage
AC
Supply voltage
24 to 240 V
Max. fluorescent lamp load
2500 VA
HAB
Z-S240/SO
Manufacturer
HAN
265282
GTIN
4015082652821
Number of contacts as normally open
1
Number of contacts as opener
1
Width in pitch units
1
Installation depth
60 mm
Function
Mechanical switch
Mounting type
DIN rail
Supply voltage
24 to 240 V
