![CDATA[The sensor offers brightness measurement and control, motion detection and adjustable limit values. It has 4 AND and 4 OR logic gates, temperature and humidity measurement with dew point calculation, and PI controller for heating and ventilation. Technical data: Housing made of plastic and glass, IP30, Ø approx. 80 mm, installation depth approx. 5 mm, installation depth approx. 31 mm. Operating temperature: -20°C to +60°C, storage: -20°C to +70°C. Operating voltage: KNX bus voltage, max. 10 mA bus current. Data output via KNX +/- bus plug terminal. Maximum of 254 group addresses and assignments, 252 communication objects. Brightness sensor: measuring range 0 lux - 2,000 lux, motion sensor with detection angle approx. 94 × 82 degrees and range approx. 5 m. Temperature sensor: -20°C to +60°C, humidity sensor: 0% rH to 100% rH. Included in delivery: sensor, pre-assembled clamps for hollow ceiling installation, support ring for box installation, data sheet and manual in several languages as download.]]>
Features
Surface
frosted
Material
plastic
Compatible with Google Assistant
N/A
Thread
No
Other bus systems
-
Operation via Bluetooth
No
EAN
4051996706823
Siemens LOGO!
No
Hager KNXeasy
No
Is expansion
No
KNX-Secure
No
Lateral reach in m
5.00
Mbus
No
Modbus TCP
No
Samsung SmartThings
N/A
Wi-Fi
No
Zigbee
No
Brightness sensor
Yes
Protection class \(IP\)
IP30
With Netatmo
No
Amazon Alexa
N/A
BAB-Tec
No
CO2 sensor
No
Gira One
No
JUNG HOME
No
KNX-RF
No
KNX-TP
Yes
Matter
No
Modbus
No
Shelly
No
Theben LUXORliving
No
Wiser Home
No
Air pressure sensor
No
Creep protection
No
Detection angle in °
360
Fits in 55 switch program
No
Humidity sensor
Yes
Installation height in m
2.50
Manufacturer type
70682
Number of areas
1
Transmission type
Cable
Apple HomeKit
N/A
Casambi
No
ENOcean
No
KNX USB interface
Yes
LED night light
No
Modbus RTU
No
VOC sensor
No
Frontal range in m
5.00
DALI
No
Class
presence detectors
Detection type/sensor type
passive infrared
Acoustic sensor
No
Detection range
circular
Free@home
No
installation location
Ceiling
integrated constant light control
Yes
Suitable for installation in switch program
No
Temperature sensor
Yes
HAN
70682
Manufacturer
Color
Black
GTIN
4051996706823
Mounting type
cavity wall
Dimming DALI-2
No
Area of application
inside
Remote control
No
Suitable for ceiling mounting
Yes
Suitable for wall mounting
No
Supply voltage
N/A
Accesories
No
