Lambda switch for 35 mm rail, 1 NO contact for 16 A / 250 V AC, contact material AgSnO2, max. switching capacity at 230 V AC: AC1 4000 VA, AC15 750 VA, incandescent and halogen lamps 2000 W, fluorescent lamps compensated 750 W, fluorescent lamps uncompensated 1000 W, energy-saving lamps 400 W, LED (230 V AC) 400 W, LV halogen lamps or LED with electronic ballast 400 W, LV halogen lamps or LED with conventional ballast 800 W, coil data 230 V AC, 6.5 VA, 2500 Ohm, width 17.5 mm, switching sequence: on/off, test button and mechanical switch position indicator, relay protection class: IP 20
| Property | Value |
| Width in division units: | 1 |
| Rated switching current: | 16 A | Control voltage 1: | 230 V |
| Control voltage type 1: | AC |
| Installation depth: | 58.4 mm |
| Function: | mechanical switch |
| Mounting type: | DIN rail |
| Frequency of control voltage 1: | 50 to 60 Hz |
| Type of supply voltage: | AC |
| Supply voltage: | 230 V |
| Max. incandescent lamp load: | 2000 W |
| Max. fluorescent lamp load: | 1000 VA |
| Max. fluorescent lamp load (duo circuit): | 1000 VA |
| Max. Fluorescent lamp load (parallel compensated): | 750 VA |
| Max. switching current (cos phi = 0.6): | 12 A |
| Manual operation possible: | yes |
| Number of contacts as normally open: | 1 |
Features
Type of voltage of the supply voltage
AC
Supply voltage
230 V
Manual operation possible
Yes
Max. fluorescent lamp load
1000 VA
Manufacturer
HAN
20.21.8.230.4000
GTIN
8012823116815
Number of contacts as normally open
1
Width in pitch units
1
Installation depth
58.4 mm
Function
Mechanical switch
Mounting type
DIN rail
Supply voltage
230V
