Plug-in/print relay 2 changeover contacts (AgNi) for 10 A / 250 V AC, contact pin pitch: 5.0 mm coil data 230 V AC, 1.2 VA, 28000 Ohm, relay protection class: RT II, meets EN 60335-1 = requirement for unattended household appliances (glow wire test)
| Property | Value |
| Number of contacts as changeover contacts: | 2 |
| Rated control supply voltage Us at AC 50 Hz: | 230 V |
| Rated control supply voltage Us at AC 60 Hz: | 230 V |
| Voltage type for actuation: | DC |
| Design of the electrical connection: | other |
| Drive, polarity: | unpolarized |
| Height: | 25 mm |
| Width: | 12.4 mm |
| Depth: | 29 mm |
| Switching behavior of the drive: | monostable |
| Type of switching contact: | single contact |
| With positively guided contacts: | no |
| With removable terminals: | no |
| Complete device with base: | no |
| Protection class (IP): | IP20 |
| Rated current: | 10 A |
| With LED display: | no |
Features
Complete device with base
No
Drive, polarity
Unpolarized
Type of switching contact
Single contact
Switching behavior of the drive
Monostable
With positively guided contacts
No
HAB
2 changeover contacts for 10A coil 230V
Minimal order
50 pcs
Manufacturer
HAN
40.62.8.230.0000
GTIN
8012823429649
Number of contacts as changeover
2
Design of the electrical connection
Other
Rated control supply voltage Us at AC 50 Hz
230V
Rated control supply voltage Us at AC 60 Hz
230V
Width
12.4 mm
Height
25 mm
With LED display
No
With removable clamps
No
Rated current
10A
IP protection)
IP20
Voltage type for actuation
DC
Depth
29 mm
