Description
Features
Reviews
Series 58, modular design with switching relays and accessories from relay series 55, for DIN rail, DC coils: 1 W, AC coils 1.5 VA, with integrated LED and EMC interference suppression and holding/dismantling clip.
| Property | Value |
| Number of contacts as changeover contacts: | 2 |
| Rated control supply voltage Us for DC: | 12 V |
| Type of voltage for actuation: | DC |
| Design of the electrical connection: | Screw connection |
| Drive, Polarity: | polarized |
| Height: | 78.4 mm |
| Width: | 27 mm |
| Depth: | 86.9 mm |
| Switching behavior of the drive: | monostable |
| Type of switching contact: | single contact |
| With positively guided contacts: | no |
| With removable terminals: | no |
| Complete device with base: | yes |
| Protection class (IP): | IP20 |
| Rated current: | 10 A |
| With LED display: | yes |
Features
Complete device with base
Yes
Drive, polarity
Polarized
Type of switching contact
Single contact
Switching behavior of the drive
Monostable
With positively guided contacts
No
Minimal order
10 pcs
Manufacturer
HAN
58.32.9.012.0050
GTIN
8012823388717
Number of contacts as changeover
2
Design of the electrical connection
Screw connection
Rated control supply voltage Us at DC
12V
Width
27 mm
Height
78.4 mm
With LED display
Yes
With removable clamps
No
Rated current
10A
IP protection)
IP20
Voltage type for actuation
DC
Depth
86.9 mm
