Description
Modular switching, control and plug-in devices as well as accessories for the CHORUS switch range. The switch can be illuminated with a bulb lamp with connecting cable, which must be ordered separately.
| Property | Value |
| Color: | white |
| Suitable for protection class (IP): | IP41 |
| Circuit type: | Toggle switch |
| Operating type: | Rocker/button |
| Number of rocker switches: | 1 |
| Mounting type: | Built-in installation |
| Push button: | yes |
| Composition: | Modular device for installation switch programs |
| Fastening type: | snap-in |
| Material: | Plastic |
| Material quality: | Thermoplastic |
| Halogen-free: | no |
| Surface: | untreated |
| Version the surface: | glossy |
| RAL number (similar): | 9003 |
| Nominal voltage: | 250 V |
| Switching current for fluorescent lamps: | 16 AX |
| Feedback contact: | no |
| Washing machine switch: | no |
| Connection type: | screw terminal |
| Number of modules (with modular design): | 1 |
| Lighting: | optional |
| Lighting type: | LED replaceable |
| Lighting function: | Control and orientation |
| Rated current: | 16 A |
| Installation depth: | 20 mm |
| Device depth: | 30 mm |
| Device width: | 22 mm |
| Device height: | 44 mm |
| With Mounting plate: | no |
| Text field/labeling area: | yes |
| Min. depth of the device box: | 25 mm |
Features
Feedback contact
No
Number of actuating rockers
1
Circuit type
Changeover switch
Lighting
Optional
Switching current for fluorescent lamps
16 AX
Push button
Yes
Washing machine switch
No
Lighting function
Control and orientation
HAB
Symbolf. illuminated 1M 1P 16AX ws
Manufacturer
HAN
GW10053
GTIN
8011564258211
Connection type
Screw terminal
Number of modules (for modular construction)
1
Surface finish
Glittering
Operating mode
Rocker/Button
Mounting type
Snap into place
Rated current
16A
Installation depth
20 mm
Color
Suitable for protection class (IP)
IP41
Device width
22 mm
Device height
44 mm
Device depth
30 mm
Halogen free
No
Min. depth of the device box
25 mm
With mounting plate
No
Mounting type
Built-in installation
Nominal voltage
250V
Surface
Untreated
RAL number (similar)
9003
Text field/label area
Yes
Material
Plastic
Material quality
Thermoplastic
Compilation
Modular device for installation switch programs
