Floor-mounted socket for industrial applications in accordance with IEC 60 309 (EN 60 309) inclination 10° nickel-plated contacts, connection technology: screw terminal, connection cross-section 1 - 2.5 mm² fine-stranded / 1.5 - 4 mm² single or multi-stranded,
| Property | Value |
| IEC current: | 16 A |
| Number of poles: | 2 |
| Connection technology: | screw terminal |
| Plug direction: | angled |
| Voltage according to EN 60309-2: | 20-25 V / 40-50 V (100-200 Hz) green |
| Time setting: | 4 h |
| Identification color: | green |
| Protection class (IP): | IP44 |
| Material: | Plastic |
| Military version: | no |
| Horizontal hole spacing: | 60 mm |
| Vertical hole spacing: | 60 mm |
| Flange dimension horizontal: | 75 mm |
| Flange dimension vertical: | 85 mm |
| Cable entry: | other |
| Rated voltage: | 20 to 50 V |
| Rated frequency: | 100 to 200 Hz |
Features
Rated frequency
100 to 200 Hz
HAB
IP44 10°2P 16A 24/42V 4H
Manufacturer
HAN
GW62269
GTIN
8011564008298
Connection technology
Screw terminal
Rated voltage
20 to 50 V
IEC current
16A
Cable entry
Other
Identification color
Green
Military version
No
Number of poles
2
IP protection)
IP44
Voltage according to EN 60309-2
20-25V / 40-50V (100-200Hz) green
Plug direction
Angled
Time position
4 hours
Material
Plastic
