Installation contactor, hum-free, 25A, 4 openers, 230V. Contactors, hum-free, built in accordance with EN 61095, DIN0637-3. The contactors are equipped with a direct current magnet system that ensures hum-free continuous operation and low switching noise. The control is carried out with alternating voltage via an integrated diode bridge. The contactors also contain: a protective circuit against overvoltage, a protective circuit to limit interference voltage peaks in the magnet system, contact position display through display window, sealable with sealing cap (accessory), auxiliary switches (accessory) can be flanged on. Integrated labeling field. Contact protection according to DIN0106 Part 100
| Property | Value |
| Type of operating voltage: | AC |
| Protection class (IP): | IP2X |
| Max. incandescent lamp load: | 1900 W |
| Rated operating current: | 25 A |
| Rated operating voltage: | 400 V |
| Max. fluorescent lamp load (parallel compensated): | 810 VA |
| Max. fluorescent lamp load (duo circuit): | 1990 VA |
| Max. Fluorescent lamp load: | 950 VA |
| Additional equipment possible: | yes |
| Slider for manual switching: | no |
| Type of actuating voltage: | AC |
| Installation depth: | 60 mm |
| Rated actuating voltage: | 230 V |
| Usage category: | 7 |
| Number of contacts as break contacts: | 4 |
Features
Rated operating current
25 A
Max. fluorescent lamp load
950 VA
Manufacturer
HAN
ESC426S
GTIN
3250612400188
Number of contacts as opener
4
Rated operating voltage
400V
Installation depth
60 mm
IP protection)
IP2X
Additional equipment possible
Yes
