Circuit breaker h3 x160 TM ADJ 3P3D 160A 40kA CTC. Circuit breaker according to DIN EN 60947-2 size x160, with thermal (adjustable) and magnetic (fixed) tripping to protect electrical systems and networks. Installation on top hat rail or mounting plate. The three different operating states can be identified by the position of the knob (ON = top, OFF = bottom, tripped = middle position). Box terminals for Cu cables are included as standard. The switches have a mechanical test button. The function of the circuit breaker can be expanded using various accessories.
| Property | Value |
| Rated continuous current Iu: | 160 A |
| Connection type main circuit: | Screw connection |
| Number of poles: | 3 |
| Device design: | Built-in device, fixed installation technology |
| Position of the connection for main circuit: | front |
| Protection class (IP): | IP40 |
| Overload release current setting: | 100 to 160 A |
| Setting range of the instantaneous short-circuit release: | 1600 A |
| Rated voltage: | 220 to 415 V |
| Rated short-circuit breaking current Icu at 400 V, 50 Hz: | 40 kA |
| Suitable for DIN rail mounting: | yes |
| Design of the actuating element: | toggle |
| Integrated Earth fault protection: | no |
| Motor drive integrated: | no |
| Motor drive optional: | no |
| With trip detector: | yes |
| Complete device with protection unit: | yes |
| DIN rail mounting optional: | no |
Features
Manufacturer
HAN
HNA160H
GTIN
3250613130862
Connection type main circuit
Screw connection
Design of the actuating element
Gag
Rated continuous current Iu
160A
Rated ultimate short-circuit breaking current Icu at 400 V, 50 Hz
40kA
Rated voltage
220 to 415 V
Setting range of the instantaneous short-circuit release
1600A
Suitable for DIN rail mounting
Yes
Device type
Built-in device Fixed installation technology
DIN rail mounting optional
No
Integrated earth fault protection
No
Complete device with protection unit
Yes
With trip detector
Yes
Motor drive integrated
No
Motor drive optional
No
Number of poles
3
Position of the connection for main circuit
In front
IP protection)
IP40
Overload release current setting
100 to 160 A
