Limit temperature: -40 ... +85 °C, Mating cycles: 500, Protection class according to IEC 60529: IP65, Housing color: green, Seal material: NBR, Flammability class according to UL 94: V-0, Net weight: 13.42 g, RoHS: compliant
| Property | Value |
| Housing design: | Body mounting housing |
| Protection class (IP), mounted: | IP65 |
| Operating temperature: | -40 to 85 °C |
| Cable feed arrangement: | other |
| Type of locking: | latching |
| With hinged lid: | no |
| EMC version: | no |
| Corrosion-resistant: | no |
| With cable gland: | no |
| UV-resistant: | no |
| Material of the housing: | Plastic |
| Flammability class of the insulating material according to UL 94: | V0 |
| Housing coating: | other |
| Bracket position: | without |
| Housing color: | green |
| Cable gland fastening type: | without |
| With nozzle: | no |
| With seal: | yes |
Features
HAB
09140010330 Han GND
Minimal order
2 pcs
Manufacturer
HAN
09140010330
GTIN
2000006827784
Housing coating
Other
Operating temperatur
-40 to 85 °C
Flammability class of the insulating material according to UL 94
V0
EMC version
No
Housing color
Green
With hinged lid
No
UV-resistant
No
Housing material
Plastic
