Limit temperature: -40 ... +125 °C, Protection class according to IEC 60529: IP44/IP65 / IP67 with sealing screw 09 20 000 9918, Housing material: die-cast zinc, Housing surface: powder-coated, Locking material: steel, Locking surface: galvanized, Net weight: 63.8 g,
| Property | Value |
| Housing design: | Built-in housing |
| Protection class (IP), mounted: | IP44 |
| Operating temperature: | -40 to 125 °C |
| Arrangement of the Cable feed: | other |
| Locking type: | Longitudinal bracket |
| With hinged lid: | yes |
| EMC version: | no |
| Corrosion-resistant: | no |
| With cable gland: | no |
| UV-resistant: | no |
| Housing material: | zinc |
| Flammability class of the insulating material according to UL 94: | other |
| Housing coating: | powder-coated |
| Bracket position: | lower part |
| Housing colour: | grey |
| Cable gland fastening type: | without |
| With nozzle: | no |
| With seal: | yes |
Features
HAB
09200030305 HAN 3A-agg-QB-K
Manufacturer
HAN
09200030305
GTIN
2000006830456
Housing coating
Powder coated
Operating temperatur
-40 to 125 °C
Flammability class of the insulating material according to UL 94
Other
EMC version
No
Housing color
Gray
With hinged lid
Yes
UV-resistant
No
Housing material
Zinc
