Housing for the construction of power switchgear combinations up to 630 A or as a single housing. Made of high-quality polycarbonate with protective insulation. Wall bushings with large openings for the electrical connection of the housings to one another. Cable entry on all housing walls via metric knockouts or mounting flanges. Housing for wall mounting also via external brackets or with mounting rails. Housing with fuse switch disconnector NH 000, 3-pole, according to IEC 60947-3 on busbars. Without supply terminals. With PE and N terminals and touch protection. Connection direction can be changed. Cover closures for tool operation.
| Property | Value |
| Housing height: | 300 mm |
| Rated operating current Ie: | 125 A |
| Size of fuse links: | NH000 |
| Rated insulation voltage Ui: | 690 V |
| Protection class (IP): | IP65 |
| Number of poles: | 3 |
| With Fuse monitoring: | no |
| Max. rated operating voltage Ue at AC: | 800 V |
Features
Rated operating current Ie
125 A
HAB
6x3xNH000 on. Collect. 250A 5-pole
Manufacturer
HAN
Mi 6494
GTIN
4012591161226
Rated insulation voltage Ui
690V
Suitable for outdoor use
No
Max. rated operating voltage Ue at AC
800V
With fuse monitoring
No
Number of poles
3
IP protection)
IP65
