IPON cable gland tested to DIN EN 50262, with metric connecting thread to DIN EN 60423, with integrated strain relief. Nominal size: M 50 for cable Ø: 32 - 38 mm Connecting thread length: 13 mm Wrench size: 60 mm Glow wire test to 0471/DIN IEC 695 Part 2-1: 850 ° Protection class: IP68, 5 bar Flame retardant: UL 94 VO Operating temperature range: -20 ° to 100 ° C Material of gland body: Polyamide Material of sealing ring: CR/NBR Material of additional material. Connection sealing ring: NBR Color: light gray RAL: 7035 (similar)
| Property | Value |
| Wrench size: | 60 mm |
| Thread pitch: | 1.5 mm |
| Nominal thread size metric/PG: | 50 |
| Suitable for cable diameters: | 32 to 38 mm |
| Protection class (IP): | IP68 |
| Operating temperature: | -20 up to 100 °C |
| Halogen-free: | yes |
| Thread length: | 13 mm |
| Thread type: | metric |
| Design: | straight |
| Color: | light gray |
| Material: | plastic |
| With strain relief: | no |
| Surface: | untreated |
| Hexagon corner dimension: | 66 mm |
| Type of seal: | Sealing ring |
| Impact resistant: | yes |
| Bending protection: | no |
| RAL number: | 7035 |
| Material quality: | Polyamide (PA) |
| Fiberglass reinforced: | no |
| With lock nut: | no |
| Multiple sealing insert: | no |
| Flat cable screw connection: | no |
| Dividable screw connection: | no |
| Explosion-tested version: | no |
| For Ex-zone gas: | without |
| For Ex-zone dust: | without |
Features
Impact resistant
Yes
Explosion-tested version
No
Nominal thread size metric/PG
50
Fiberglass reinforced
No
Suitable for cable diameter
32 to 38mm
Wrench size
60 mm
HAB
1234M5001 metric
Manufacturer
HAN
1234M5001
GTIN
4011126344578
Version
Straight
Operating temperature
-20 to 100 °C
Color
Thread type
Metric
Thread length
13 mm
Thread
1.5 mm
Halogen free
Yes
With strain relief
No
Surface
Untreated
RAL number
7035
IP protection)
IP68
Material
Plastic
Material quality
Polyamide (PA)
