INFRAcontrol R 180° UP IP40Infrared motion switch, (50x50mm DIN size 49075), including 2 intermediate frames, flush-mounted, protection class IP40, switch-off warning, master/slave function, detection range 180°, detection range approx. 9 m, setting time 5-stage: 20 sec./ 1 min. / 5 min. / 15 min./30 min., pulse output ON: 1 sec. / OFF: 9 sec. Twilight threshold continuously adjustable, with switch: permanent on, automatic, permanent off, basic circuit:
| Property | Value |
| Depth: | 65,000 mm |
| Width: | 50,000 mm |
| Height: | 50,000 mm |
| Design: | Motion detector |
| Voltage type: | AC |
| Protection class (IP): | IP40 |
| Max. switching capacity: | 2000 W |
| Min. duty cycle: | 20 s |
| Max. Duty cycle: | 30 min |
| Max. inrush current: | 10 A |
| Max. range to one side: | 9,000 m |
| Max. Frontal range: | 9,000 m |
| Horizontal detection angle: | 0 to 180 ° |
| Color: | white |
| RAL number (similar): | 9010 |
| Material: | plastic |
| Installation height: | 1,200 m |
| Installation type: | flush-mounted |
| Response brightness: | 5 to 1000 lx |
| Response brightness adjustable: | yes |
| Creep-under protection: | yes |
| Temperature: | 0 to 45 °C |
| Response sensitivity adjustable: | yes |
| Sensor type: | passive infrared |
| Surface finish: | glossy |
| Surface protection: | untreated |
| Material quality: | thermoplastic |
| Diameter of detection field on floor: | 6.00 m |
| Number of switching zones: | 3 |
| Sensor swivel range, vertical: | 0 ° |
| Sensor swivel range, horizontal: | 0 ° |
| Halogen-free: | yes |
| Constant light control: | no |
| HVAC control: | no |
| Forced shutdown: | yes |
| Animal corridor: | no |
| Networkable: | no |
| Automatic stair light: | no |
| Bypass switch: | yes |
| Suitable for wireless transmission: | no |
| Remote controllable: | no |
| With signal unit: | no |
| Alarm function: | no |
| Teach function for Response brightness: | no |
| Dimming function with dimming insert: | no |
| Transparent: | no |
| With remote control: | no |
| Suitable for C load: | yes |
| With DALI interface: | no |
| Extension input: | yes |
| Forced switching on: | yes |
| Suitable for ceiling mounting: | no |
| Connection type: | screw terminal |
| Antibacterial treatment: | no |
| Diameter: | 50 mm |
| Installation width: | 50,000 mm |
| Installation depth: | 31,000 mm |
| Installation length: | 32,000 mm |
| Installation diameter: | 50 mm |
| Min. Depth of the device box: | 32,000 mm |
| Max. switching capacity LED: | 500 W |
| Compatible with Apple HomeKit: | no |
| Compatible with Google Assistant: | no |
| Compatible with Amazon Alexa: | no |
| IFTTT support available: | no |
Features
Bridging switch
Yes
With signal unit
No
Number of switching zones
3
Response brightness
5 to 1000 lx
Forced shutdown
Yes
Max. inrush current
10 A
Forced switching on
Yes
HAB
INFRAcontrol R 180° pure white
Manufacturer
HAN
840629058
GTIN
4008224594493
Dimming function with dimming insert
No
Alarm function
No
Connection type
Screw terminal
Response sensitivity adjustable
Yes
Response brightness adjustable
Yes
Antibacterial treatment
No
Version
Motion detector
Surface finish
Glittering
Width
50,000 mm
Diameter
50 mm
Installation width
50,000 mm
Installation diameter
50 mm
Installation length
32,000 mm
Installation depth
31,000 mm
Detection angle horizontal
0 to 180 °
Color
Remote controllable
No
Suitable for C-load
Yes
Suitable for ceiling mounting
No
Suitable for wireless transmission
No
HVAC control
No
Halogen free
Yes
Height
50,000 mm
IFTTT support available
No
Compatible with Amazon Alexa
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Constant light control
No
Max. duty cycle
30 min
Max. range frontal
9,000m
Max. range to one side
9,000m
Max. switching capacity
2000W
Min. duty cycle
20s
Min. depth of the device box
32,000 mm
With DALI interface
No
With remote
No
Mounting type
Flush-mounted
Extension input
Yes
Surface protection
Untreated
RAL number (similar)
9010
IP protection)
IP40
Sensor type
Passive infrared
Voltage type
AC
Teach function for response brightness
No
Temperature
0 to 45 °C
Depth
65,000 mm
Animal corridor
No
Transparent
No
Networkable
No
Material
Plastic
Material quality
Thermoplastic
