Product family advantages: Homogeneous color changes. Great design freedom thanks to the flexibility and cuttability of the module. Easy installation and contacting. Protection class: IP00. Tool-free connection using the optional CONNECT system for RGB. Easy installation on many smooth surfaces using the self-adhesive tape on the back. Product family properties: Flexible and divisible LED strip with inline multichip RGB LEDs. RGBW, all types: full individual bins on each color and white. RGB LF200C and LF05CE: binning on white (RGB mix). RGB LF05CA2: binning on individual colors R, G, B. Areas of application: Effect lighting in architecture. Coupling into surface light guides and displays. Dynamic effects in public areas. Technical equipment: Easier connection with optional, matching CONNECT system for RGB. Fast installation with optional SLIM TRACK system.
| Property | Value |
| Lamp power per meter: | 9.8 W |
| With connection set: | yes |
| Length of the individual sections: | 25.0 mm |
| Number of lamps per meter: | 80 |
| Smallest bending radius: | 20 mm |
| Width: | 10.0 mm |
| Length: | 6000 mm |
| Beam angle: | 120 ° |
| Design: | Band |
| With End piece: | no |
| Color temperature: | 2700 K |
| Light source: | LED not replaceable |
| Protection class (IP) : | IP00 |
| Self-adhesive: | yes |
| Voltage type: | DC |
| Number of lamps per base: | 24 |
| Lamp power per base: | 2.9 W |
| Luminous flux per meter: | 697 lm |
| Lamp voltage: | 24 V |
| Energy efficiency class of the built-in Light source: | G |
| Max. system power: | 58 W |
| Light color: | RGBW |
| Color rendering index CRI: | 80-89 |
| Height/depth: | 1.40 mm |
| With protective cover: | no |
| Number of poles: | 5 |
| Connection type: | other |
