Product family advantages: High light quality thanks to low output ripple current. High flexibility thanks to four different output currents. Small housing for flexible luminaire designs. High efficiency. Product family properties: Supply voltage: 220-240 V. Mains frequency: 50 Hz, 60 Hz. Mains voltage: 198-264 V. Safety in accordance with EN 61347-1, 61347-2-13, 62384. Radio interference suppression: in accordance with EN 55015. Mains current harmonics in accordance with EN 61000-3-2. Immunity, interference resistance in accordance with EN 61547. Service life: up to 50,000 h (at Tc = 70 °C, max. 10% failure rate). Strain relief for independent installation. Areas of application: Suitable for downlights, spotlights and LED panels. Suitable for luminaires of protection class I and II.
| Feature | Value |
| Output power: | 21 W |
| Length: | 97.0 mm |
| Width: | 43.0 mm |
| Height: | 29.5 mm |
| Protection class (IP) : | IP20 |
| Design: | static |
| Housing: | plastic housing |
| Suitable for outdoor use: | no |
| Output voltage: | 42 V |
| Suitable for Constant voltage: | no |
| Suitable for constant current: | yes |
| Output current: | 250 mA |
| Suitable for direct voltage (primary side): | no |
| Protection class: | II |
| Dimming 0-10 V: | no |
| Dimming 1-10 V: | no |
| Dimming DALI: | no |
| Dimming DSI: | no |
| Dimming DMX: | no |
| Dimming potentiometer (device integrated): | no |
| Dimming GPRS: | no |
| Dimming LineSwitch: | no |
| Dimming manufacturer-specific: | no |
| Dimming mains voltage modulation: | no |
| Dimming trailing edge: | no |
| Dimming leading edge: | no |
| Dimming programmable: | no |
| Dimming RF: | no |
| Dimming Sine Wave Reduction: | no |
| Dimming Touch and Dim: | no |
| Dimming Zigbee: | no |
| Dimming with push button: | no |
| Without dimming function: | yes |
