Product family advantages: Flexible current setting (DIP switch - 4 currents). Service life: up to 100,000 hours (at Tc = 65 °C, max. 10% failure rate). High efficiency. High light quality thanks to low output ripple current (current ripple). Meets safety requirements through overload, overtemperature and hot plug protection. Product family properties: Mains frequency: 0 Hz, 50 Hz, 60 Hz. Versatile application area thanks to output power of up to 75 W. Supply voltage: 220240 V. Available with output current range: up to 1,400 mA. SELV system. Areas of application: Linear lighting solutions for offices, educational institutions, industrial buildings, storage areas and retail. Installation in emergency lighting systems in accordance with IEC 61347-2-13, Appendix J. Suitable for luminaires of protection class I.
| Property | Value |
| Protection class (IP): | IP20 |
| Output voltage: | 27 to 51 V |
| Protection class: | I |
| Length: | 280.00 mm |
| Width: | 30.00 mm |
| Height: | 21.00 mm |
| Design: | static |
| Housing: | metal housing |
| Suitable for outdoor use: | no |
| Suitable for Constant voltage: | no |
| Suitable for constant current: | yes |
| Suitable for direct voltage (primary side): | yes |
| Dimming 0-10 V: | no |
| Dimming 1-10 V: | no |
| Dimming DALI: | no |
| Dimming DSI: | no |
| Dimming DMX: | no |
| Dimming potentiometer (integrated in device): | no |
| Dimming LineSwitch: | no |
| Dimming manufacturer-specific: | no |
| Dimming mains voltage modulation: | no |
| Dimming trailing edge: | no |
| Dimming leading edge: | no |
| Dimming programmable: | no |
| Dimming RF: | no |
| Dimming Sine Wave Reduction: | no |
| Dimming Touch and Dim: | no |
| Dimming Zigbee: | no |
| Dimming with Push button: | no |
| Without dimming function: | yes |
