Screw connection PG36, cable ø: min.: 22 mm, max.: 34.5 mm
| Property | Value |
| Wrench size: | 17 mm |
| Thread pitch: | 1.5 mm |
| Nominal thread size metric/PG: | 16 |
| Suitable for cable diameters: | 5.5 to 9.5 mm |
| Protection class (IP): | IP68 |
| Operating temperature: | -25 to 85 °C |
| Halogen-free: | yes |
| Thread length: | 5 mm |
| Thread type: | metric |
| Design: | straight |
| Material: | metal |
| Surface: | untreated |
| Hexagon corner dimension: | 19 mm |
| Impact-resistant: | yes |
| Bending protection: | no |
| Fiberglass reinforced: | no |
| With lock nut: | no |
| Flat cable gland: | no |
| Dividable gland: | no |
| Explosion-tested version: | no |
| For Ex-Zone Gas: | without |
| For Ex-Zone Dust: | without |
Features
Insert Module Type
Light switch covers
Impact resistant
Yes
Explosion-tested version
No
Nominal thread size metric/PG
16
Fiberglass reinforced
No
Suitable for cable diameter
5.5 to 9.5mm
Wrench size
17 mm
Minimal order
10 pcs
Manufacturer
HAN
095517
GTIN
3245060955175
Version
Straight
Operating temperature
-25 to 85 °C
Thread type
Metric
Thread length
5 mm
Thread
1.5 mm
Halogen free
Yes
Surface
Untreated
IP protection)
IP68
Material
Metal
