Inserts are supplied including a rocker/cover and protective cover. Fastening using screws or expanding claws - inserts for screw fastening can be retrofitted with expanding claws Order No. 6650 99. Connection via plug-in (SL) or screw terminals (SK).
| Property | Value |
| Color: | white |
| Suitable for protection class (IP): | IP31 |
| Circuit type: | Toggle switch |
| Operating type: | Rocker/button |
| Number of rocker switches: | 2 |
| Mounting type: | Flush-mounted |
| Push button: | no |
| Composition: | Base element with central cover plate |
| Fastening type: | Screw fastening |
| Material: | Plastic |
| Material quality: | Thermoplastic |
| Halogen-free: | yes |
| Surface: | untreated |
| Surface finish: | glossy |
| RAL number (similar): | 9003 |
| Nominal voltage: | 250 V |
| Switching current for fluorescent lamps: | 10 AX |
| Feedback contact: | no |
| Washing machine switch: | no |
| Connection type: | other |
| Lighting: | no |
| Lighting type: | other |
| Lighting function: | other |
| Rated current: | 10 A |
| Installation depth: | 20 mm |
| Device depth: | 34 mm |
| Device width: | 76 mm |
| Device height: | 76 mm |
| With mounting plate: | yes |
| Text field/labeling area: | no |
| Min. Depth of the device box: | 30 mm |
Features
Insert Module Type
Light switch covers
HAN
664702
Manufacturer
Color
White
GTIN
3245066647029
Feedback contact
No
Circuit type
Changeover switch
Lighting
No
Switching current for fluorescent lamps
10 AX
Push button
No
Washing machine switch
No
Lighting function
Other
Number of actuating rockers
2
Operating mode
Rocker/Button
Mounting type
Screw fastening
Rated current
10A
Installation depth
20 mm
Color
Connection type
Other
Suitable for protection class (IP)
IP31
Device width
76 mm
Device height
76 mm
Device depth
34 mm
Halogen free
Yes
Min. depth of the device box
30 mm
With mounting plate
Yes
Mounting type
Flush-mounted
Nominal voltage
250V
Surface
Untreated
RAL number (similar)
9003
Text field/label area
No
Material
Plastic
Material quality
Thermoplastic
Compilation
Base element with central cover plate
Surface finish
Glittering
