suitable for spreading claw and screw fastening and are supplied with a transparent dust cover, for rigid and flexible conductors using plug-in (SL) or screw terminals (SK), professional packaging (cardboard box)
| Property | Value |
| Color: | gray |
| Suitable for protection class (IP): | IP20 |
| Circuit type: | Toggle switch |
| Operating type: | Rocker/button |
| Number of actuating rockers: | 1 |
| Installation type: | Flush-mounted |
| Push button: | no |
| Composition: | Control element |
| Fastening type: | Claw/screw fastening |
| Material: | Plastic |
| Material quality: | Thermoplastic |
| Halogen-free: | yes |
| Surface: | untreated |
| Version the surface: | matt |
| RAL number (similar): | 9013 |
| Nominal voltage: | 250 V |
| Switching current for fluorescent lamps: | 16 AX |
| Feedback contact: | no |
| Washing machine switch: | no |
| Connection type: | other |
| Lighting: | no |
| Lighting type: | other |
| Lighting function: | other |
| Rated current: | 16 A |
| Installation depth: | 27.5 mm |
| Device depth: | 37.2 mm |
| Device width: | 74.7 mm |
| Device height: | 74.7 mm |
| With mounting plate: | yes |
| Text field/labeling area: | no |
| Min. depth of the device box: | 30 mm |
Features
Insert Module Type
Light switch inserts
HAN
752027
Manufacturer
GTIN
3414970575364
Feedback contact
No
Circuit type
Changeover switch
Lighting
No
Switching current for fluorescent lamps
16 AX
Push button
No
Washing machine switch
No
Lighting function
Other
Number of actuating rockers
1
Operating mode
Rocker/Button
Mounting type
Claw/screw fastening
Rated current
16A
Installation depth
27.5 mm
Color
Connection type
Other
Suitable for protection class (IP)
IP20
Device width
74.7 mm
Device height
74.7 mm
Device depth
37.2 mm
Halogen free
Yes
Min. depth of the device box
30 mm
With mounting plate
Yes
Mounting type
Flush-mounted
Nominal voltage
250V
Surface
Untreated
RAL number (similar)
9013
Text field/label area
No
Material
Plastic
Material quality
Thermoplastic
Compilation
Control element
Surface finish
Frosted
