1 changeover contact. Equipped with neon lamp Order No. 7758 90. Suitable for cards (L x W x H): 86 x 54 x 1.4 mm (credit card). Cover Order No. 77xx 54 use
| Property | Value |
| Color: | gray |
| Suitable for protection class (IP): | IP21 |
| Circuit type: | Off switch 1-pole |
| Operating type: | Hotel card |
| Number of actuating rockers: | 1 |
| Mounting type: | Flush-mounted |
| Push button: | no |
| Composition: | Base element with central cover plate |
| Fastening type: | Claw/screw fastening |
| Material: | Plastic |
| Material quality: | Thermoplastic |
| Halogen-free: | yes |
| Surface: | untreated |
| Surface finish: | matt |
| RAL number (similar): | 7016 |
| Nominal voltage: | 250 V |
| Switching current for fluorescent lamps: | 10 AX |
| Feedback contact: | no |
| Washing machine switch: | no |
| Connection type: | other |
| Lighting: | yes |
| Lighting type: | neon lamp |
| Lighting function: | Orientation |
| Rated current: | 10 A |
| Installation depth: | 21.5 mm |
| Device depth: | 38 mm |
| Device width: | 71 mm |
| Device height: | 71 mm |
| With mounting plate: | yes |
| Text field/labeling area: | no |
| Min. Depth of the device box: | 30 mm |
Features
Insert Module Type
Light switch covers
Feedback contact
No
Number of actuating rockers
1
Circuit type
1-pole switch
Lighting
Yes
Switching current for fluorescent lamps
10 AX
Push button
No
Washing machine switch
No
Lighting function
Orientation
Manufacturer
HAN
775954
GTIN
3245067759547
Connection type
Other
Surface finish
Frosted
Operating mode
Hotel card
Mounting type
Claw/screw fastening
Rated current
10A
Installation depth
21.5 mm
Color
Suitable for protection class (IP)
IP21
Device width
71 mm
Device height
71 mm
Device depth
38 mm
Halogen free
Yes
Min. depth of the device box
30 mm
With mounting plate
Yes
Mounting type
Flush-mounted
Nominal voltage
250V
Surface
Untreated
RAL number (similar)
7016
Text field/label area
No
Material
Plastic
Material quality
Thermoplastic
Compilation
Base element with central cover plate
