![CDATA[DALI LED driver (CC) with 2 output channels, control of Tunable White capable luminaires via DALI address (DT8). Operating modes: Balance&Dim, Dim2Warm, SwitchDim2 (control option via 2 button inputs without DALI) Electrical data: Supply Uin: 12VDC-48VDC Max. connection current Iinmax: 350mA/500mA Max. output current per channel: 350mA/500mA Output voltage range Uled: 3V-45V (with 48V supply) Control input: -DALI -SwitchDim2 Current requirement DALI: 2mA Number of DALI addresses: Operating mode DT8, Dim2Warm: 1 Operating mode Balance&Dim: 2 Standby losses (12V): ~ 180mW common positive pole Technical data: State after power on: adjustable via DALI: 0% to 100% or last value Storage and transport temperature: -20 to +75 degrees Celsius Operating temperature Ta: -20 to +60 degrees Celsius Expected service life: >,100000h at Tc<,75 degrees Celsius Protection class: IP20 max. cable cross-section: up to 1.5mm² -Supply (V+, V-): up to 2.5mm² Dimensions: 120mmx30mmx22mm Installation/housing shape: ceiling recessed]]>
Features
Compatible with Google Assistant
N/A
Thread
No
Other bus systems
-
Operation via Bluetooth
No
EAN
9010342011894
Siemens LOGO!
No
Hager KNXeasy
No
KNX-Secure
No
Mbus
No
Modbus TCP
No
Samsung SmartThings
N/A
Size of connection terminal in mm2
2.50
Wi-Fi
No
Zigbee
No
active power measurement
No
Connection type CC
common anode
Fan coil
No
Louvre
No
Nominal voltage outputs
-
Output current in mA
350
Switching
no
With Netatmo
No
Amazon Alexa
N/A
BAB-Tec
No
DALI Device Type
DT8
Gira One
No
Heating
No
JUNG HOME
No
KNX-RF
No
KNX-TP
No
Matter
No
Modbus
No
On-site/manual operation
No
Shelly
No
Theben LUXORliving
No
Wiser Home
No
Color control
Tunable White
Different phases can be connected
No
Division units
-
Manufacturer type
DALI DT8 CW-WW CC-350DE
Output power in W
0.00
Transmission type
Cable
Apple HomeKit
N/A
Casambi
No
ENOcean
No
KNX USB interface
No
Modbus RTU
No
Parallel operation of channels possible
No
DALI
Yes
Class
dimming actuators
Dimming process
PWM constant current CC
Day/night function
No
Dimming
Yes
Free@home
No
HAN
86458911-350DE
Manufacturer
LUNATONE
GTIN
9010342011894
Number of outputs
2
Mounting type
ceiling-mounted
