MULTIFIX 60 is a system for power distribution on copper bars with a 60mm busbar spacing, which consists of a variety of modular components that can be combined with one another. The system can withstand loads of up to 630 A, 400 VAC, 500 VAC, 690 VAC, 45 62 Hz. The short-circuit strength is tested according to 0660 Part 500 and IEC 60439-1. MULTIFIX 60 can be used in 3-, 4- and 5-pole versions. The drill-free assembly of the components of the MULTIFIX 60 system offers great flexibility when expanding and changing existing installations and systems and guarantees a short assembly time. D02 fuse switch strips 63A, 400VAC can be switched in 3-pole, can be mounted without drilling by directly snapping on and lock themselves automatically. They are designed for busbars with a width of 12 to 30 mm and a thickness of 5 to 10 mm. The device width of only 27 mm allows space-saving and system-compatible installation and the fuse plugs according to EN 50110-1 enable installation without a screw cap. According to IEC/EN 60439-1 and 0660 Part 500 for D01 fuse links (with dowel sleeves for D02 and retaining spring) and D02 fuse links according to EN 60 269-3, 0636/Part 30, DIN 49 522.
| Property | Value |
| Number of poles: | 1 |
| Weight unit: | KG |
| Mounting type: | other |
| Rated voltage: | 440 V |
| Material: | other |
| Size: | other |
