For data connection and communication technology. Please order the corresponding slots separately.
To be completed with:
Blind insert System M, System Design, System Area 464380.
Insert for 9-pin D-Subminiature connector System M, System Design, System Area 464391.
Insert for 15-pin D-Subminiature connector System M, System Design, System Area 464392.
Insert for 25-pin D-Subminiature connector System M, System Design, System Area 464393.
Insert for BNC/TNC sockets System M, System Design, System Area 464395.
Insert for Twinax sockets System M, System Design, System Area 464397.
Insert for Modular Jack Cat. 5 connector System M, System Design, System Area 464399.
Insert for connector Modular Jack System M, System Design, System Area 464398.
Insert for audio socket XLR System M, System Design, System Area 464390.
Insert for audio plug XLR System M, System Design, System Area 464389.
Insert with high-end loudspeaker connector System M, System Design, System Area 464387.
Insert for IBM plug System M, System Design, System Area 464379.
Insert for optical fiber ST couplings System M, System Design, System Area 464386.
Insert for ACO installation boxes System M, System Design, System Area 464396.
Insert for data communication connectors from Thomas + Betts System M, System Design, System Area 464394.
Insert for IBM system ACS Type Mini C System M, System Design, System Area 464383.
Insert for Duplex SC System M, System Design, System Area 464381.
Insert for Reichle & De-Massari System M, System Design, System Area 464384.
Accessories:
Labeling strips for switches, sockets System Design MEG3926-6000.
Scope of delivery: Without inserts.
Material: Brilliant thermoplastic.
Color: Lotus white.
| Property | Value |
| Mounting type: | Mounting with screw |
| Color: | white |
| RAL number (similar): | 9003 |
| Device height: | 71.0 mm |
| Device width: | 71.0 mm |
| Device depth: | 41.0 mm |
| Labeling field: | with labeling field |
| Use: | other |
| With dust protection: | no |
| Mounting type: | flush-mounted |
| Surface: | untreated |
| With hinged lid: | no |
| Suitable for protection class (IP): | IP20 |
| Composition: | Basic element with central cover plate |
| Support ring: | yes |
| With print: | no |
| Material: | Plastic |
| Material quality: | Thermoplastic |
| Halogen-free: | yes |
| Surface finish: | glossy |
| With strain relief: | no |
| Lamp terminal: | no |
| Transparent: | no |
| Outlet direction: | angled |
| With sockets/couplings: | no |
| Suitable for number of sockets/couplings: | 1.0 |
| Sockets shielded: | no |
| Housing shielded: | no |
