Ideal for all standard applications (presence areas) in offices, meeting rooms, lounges, basements, etc.
Presence detector with minimal power consumption of 0.25 W
Master-slave circuit for inexpensive enlargement of the detection area
Can be used in installations as a single device or in combination with other Züblin master and slave devices, e.g. B. 25453, 25458, 25459, 25464, 25469
Can be programmed as a fully or semi-automatic device
Manual control via external button possible
IP44 for indoor and outdoor use (splash protection)
Technical data
Mounting position ceiling
Mounting type surface-mounted
Nominal voltage 230V / 50 Hz
Standby consumption 0.25 W
Power consumption 0.6 W
Switching capacity ohmic (cos 1.0) 2000W / 8.7A
Switching capacity inductive (cos 0.5) 1000VA / 4.35A
Switching capacity LED 300W
Networking Relay
Type of control daylight-dependent on/off
Number PIR sensors 3
Detection angle 360°
Detection radius passage area 7.00 m
Detection radius stay area 3.00 m
Installation height 2.00 to 6.00 m
Twilight controller 5 - 2000 lx
Time delay short pulse (approx. 1 s), 10 s - 20 min
Protection class IP44, protected outdoor area
Temperature range -20 to 40 °C
Visible dimensions [mm] 105x75
Weight 0.25 kg
Cover round
Color white
| Property | Value |
| Depth: | 75 mm |
| Width: | 105 mm |
| Height: | 105 mm |
| Version: | Presence detector |
| Color: | white |
| Nominal voltage: | 230 V |
| RAL number (similar): | 9010 |
| Material: | Plastic |
| Mounting type: | Surface-mounted |
| Response brightness: | 5 to 2000 lx |
| Protection class (IP): | IP44 |
| Max. switching capacity: | 2000 W |
| Voltage type: | AC |
| Max. range to one side: | 8 m |
| Scan angle: | 360 ° |
| Suitable for wall mounting: | no |
| Min. duty cycle: | 10 s |
| Max. Duty cycle: | 20 min |
| Creep-under protection/rear field monitoring: | no |
| Temperature: | -20 to 40 °C |
| Adjustable response brightness: | yes |
| Adjustable response sensitivity: | yes |
| Max. presence area: | 201 m² |
| Max. frontal range: | 8 m |
| Max. Inrush current: | 8.7 A |
| Sensor type: | passive infrared |
| Optimal installation height: | 4 m |
| Surface finish: | matt |
| Surface: | untreated |
| Material quality: | thermoplastic |
| Detection field diameter on floor: | 16 m |
| Number of switching zones: | 1 |
| Detection angle horizontal: | 0 to 360 ° |
| Frequency: | 50 Hz |
| Halogen-free: | yes |
| Constant light control: | no |
| HVAC control: | no |
| Forced shutdown: | yes |
| Animal corridor: | no |
| Networkable: | yes |
| Staircase monitoring: | no |
| Suitable for wireless transmission: | no |
| Remote control: | yes |
| With signal unit: | no |
| Alarm function: | no |
| Teach function for response brightness: | yes |
| Transparent: | no |
| With remote control: | no |
| Suitable for C load: | yes |
| With DALI interface: | no |
| Extension input: | yes |
| Forced switching on: | yes |
| Suitable for ceiling mounting: | yes |
| Connection type: | Plug-in terminal |
| Antibacterial Treatment: | yes |
| Min. inrush current: | 5 A |
| Diameter: | 105 mm |
