AP motion detector for ceiling mounting / Zueblin Swiss Garde 360 presence DALI Master A-Comfort high ceiling 32m / Addressable 4-zone DALI detector with integrated DALI power supply / Operation in master/slave configuration with up to 10 DALI slave devices / 1x relay HVAC channel / 3 PIR sensors with 360° detection range (3x 120°) / Range approx. 32m at 8m height / Installation height 3.5-8 meters / IP54 increased splash-proof / Time controller: 5min to / Button input dimming / Slave input / Configuration via remote control
| Property | Value |
| Depth: | 64 mm |
| Width: | 117 mm |
| Height: | 117 mm |
| Version: | motion detector |
| Color: | white |
| Nominal voltage: | 230 V |
| RAL number (similar): | 9010 |
| Material: | Plastic |
| Mounting type: | Surface-mounted |
| Response brightness: | 100 to 2000 lx |
| Protection class (IP): | IP54 |
| Max. switching power: | 2300 W |
| Voltage type: | AC |
| Max. range to one side: | 16 m |
| Scan angle: | 360 ° |
| Suitable for wall mounting: | no |
| Min. duty cycle: | 300 s |
| Max. Duty cycle: | 9999 min |
| Creep-under protection/rear field monitoring: | no |
| Temperature: | -5 to 50 °C |
| Adjustable response brightness: | yes |
| Adjustable response sensitivity: | yes |
| Max. presence area: | 804 m² |
| Max. frontal range: | 16 m |
| Max. Inrush current: | 10 A |
| Sensor type: | passive infrared |
| Optimal installation height: | 6 m |
| Surface finish: | matt |
| Material quality: | thermoplastic |
| Detection field diameter on floor: | 32 m |
| Control current: | 200 mA |
| Number of switching zones: | 3 |
| Switch-off delay: | 9999 s |
| Horizontal detection angle: | 0 to 360 ° |
| Frequency: | 50 Hz |
| Halogen-free: | yes |
| Constant light control: | yes |
| HVAC control: | no |
| Forced shutdown: | no |
| Animal corridor: | no |
| Networkable: | yes |
| Staircase monitoring: | no |
| Bypass switch: | no |
| Suitable for wireless transmission: | no |
| Remote controllable: | yes |
| With signal unit: | no |
| Alarm function: | no |
| Teach function for response brightness: | yes |
| Dimming function with dimming insert: | yes |
| Transparent: | no |
| With remote control: | yes |
| Suitable for C load: | yes |
| With DALI interface: | yes |
| Extension input: | yes |
| Suitable for ceiling mounting: | yes |
| Connection type: | screw terminal |
| Antibacterial treatment: | no |
| Impact resistance: | IK02 |
| Min. inrush current: | 0.000001 A |
| Diameter: | 117 mm |
Features
Bridging switch
No
With signal unit
No
Number of switching zones
3
Response brightness
100 to 2000 lx
Forced shutdown
No
Max. inrush current
10 A
Scanning angle
360 °
Max. presence range
804 m²
HAB
Swiss Garde 360 DALI Master A-Comfort AP
Manufacturer
HAN
41761
GTIN
3505100417613
Dimming function with dimming insert
Yes
Alarm function
No
Connection type
Screw terminal
Response sensitivity adjustable
Yes
Response brightness adjustable
Yes
Antibacterial treatment
No
Version
Motion detector
Surface finish
Frosted
Width
117 mm
Diameter
117 mm
Detection field diameter on floor
32m
Detection angle horizontal
0 to 360 °
Color
Remote controllable
Yes
Frequency
50Hz
Suitable for C-load
Yes
Suitable for ceiling mounting
Yes
Suitable for wall mounting
No
Suitable for wireless transmission
No
HVAC control
No
Halogen free
Yes
Height
117 mm
Constant light control
Yes
Max. duty cycle
9999mins
Max. range frontal
16m
Max. range to one side
16m
Max. switching capacity
2300W
Min. duty cycle
300s
With DALI interface
Yes
With remote
Yes
Mounting type
Surface-mounted
Extension input
Yes
Nominal voltage
230V
Optimal mounting height
6m
RAL number (similar)
9010
Impact resistance
IK02
IP protection)
IP54
Sensor type
Passive infrared
Voltage type
AC
Teach function for response brightness
Yes
Temperature
-5 to 50 °C
Depth
64 mm
Animal corridor
No
Transparent
No
Staircase monitoring
No
Creep protection/rear field monitoring
No
Networkable
Yes
Material
Plastic
Material quality
Thermoplastic
