Printed circuit board direct connector, nominal cross section: 1.5 mm, color: green, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: tin, number of potentials: 8, number of rows: 2, number of poles per row: 4, number of connections: 8, article family: CDDC 1.5/..-PV, pitch: 3.5 mm, connection type: crimp connection, assembly: SKEDD - direct plug-in technology, conductor/board connection direction: 90 °, pin layout: linear pinning, plug-in system: SKEDD, locking: snap-in locking, fastening type: snap-in flange, packaging type: packed in a box
| Property | Value |
| Connectable cable type: | other |
| Connectable conductor cross-section, finely stranded without wire end ferrule: | 0.14 to 1.5 mm² |
| Number of plug contact rows: | 2 |
| Design of the electrical connection: | Crimp connection |
| Rated voltage: | 160 V |
| Rated impulse voltage: | 2.5 kV |
| Rated current In: | 8 A |
| Operating temperature: | -55 to 105 °C |
| Flammability class of the insulating material according to UL 94: | V0 |
| Housing color: | green |
| With protective conductor: | no |
| Pitch of connections: | 3.5 mm |
| Pitch of contacts: | 3.5 mm |
| Overvoltage category: | III |
| Degree of pollution: | 2 |
| Housing material: | other |
| Material of the insulating body: | other |
| Angle contact/conductor connection: | other |
| Connection type: | other |
| Number of poles: | 8 |
| Housing coating: | other |
Features
Rated surge voltage
2.5 kV
HAB
CDDC 1.5/ 4-PV-3.5
Minimal order
150 pcs
Manufacturer
HAN
1016512
GTIN
4055626498805
Design of the electrical connection
Crimp connection
Rated voltage
160V
Rated current In
8A
Housing coating
Other
Operating temperatur
-55 to 105 °C
Flammability class of the insulating material according to UL 94
V0
Housing color
Green
Number of poles
8
Connection type
Other
Degree of contamination
2
Housing material
Other
Overvoltage category
III
