Pin header, nominal cross section: 1.5 mm, color: red, nominal current: 12 A (depending on the plug used), rated voltage (III/2): 320 V, contact surface: tin, contact type: pin (male), number of rows: 1, number of positions per row: 4, article family: PST 1.3/..-V, pitch: 5 mm, assembly: THR soldering, pin layout: linear pinning, pin length [P]: 3.5 mm, plug system: COMBICON COMPACT PST 1.3, locking: without, fastening type: without, packaging type: packed in a box
| Property | Value |
| Number of plug contact rows: | 1 |
| Type of Banding: | Cardboard (for SMD) |
| Type of PCB mounting: | other |
| Design of electrical connection: | other |
| Mounting type: | other |
| Rated voltage: | 320 V |
| Rated impulse voltage: | 4 kV |
| Rated current In: | 12 A |
| Operating temperature: | -40 to 100 °C |
| Flammability class of the insulating material according to UL 94: | V0 |
| Diameter of the connection pin: | 1.3 mm |
| Housing color: | red |
| Contact design: | pin |
| Length of the pin: | 3.5 mm |
| Pitch of the connections: | 5 mm |
| Pitch of the contacts: | 5 mm |
| Connector design: | fixed connector |
| Overvoltage category: | III |
| Pollution level: | 2 |
| Contact coating material: | tin |
| Insulating body material: | other |
| Angle PCB/contact: | other |
| Connection type: | PCB to cable |
Features
Rated surge voltage
4 kV
HAB
PST 1.3/ 4-5.0 RD VPE250
Minimal order
250 pcs
Manufacturer
HAN
1107441
GTIN
4063151006983
Design of the electrical connection
Other
Mounting type
Other
Rated voltage
320V
Rated current In
12A
Operating temperatur
-40 to 100 °C
Flammability class of the insulating material according to UL 94
V0
Housing color
Red
Connection type
PCB to cable
Degree of contamination
2
Overvoltage category
III
