PCB connector, nominal cross section: 2.5 mm², color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: tin, contact type: socket (female), number of rows: 1, number of positions per row: 12, article family: FKC 2.5/..-STF, pitch: 5.08 mm, connection type: push-in spring connection, connection direction conductor/PCB: 0 °, locking hook: - locking hook, plug-in system: CLASSIC COMBICON, locking: screw locking, fastening type: screw flange, packaging type: packed in a cardboard box
| Property | Value |
| Connectable conductor cross section, single-wire: | 0.2 to 2.5 mm² |
| Connectable conductor cross-section, finely stranded without wire end ferrule: | 0.2 to 2.5 mm² |
| Rated current In: | 12 A |
| Flammability class of the insulating material according to UL 94: | V0 |
| Housing color: | green |
| Contact design: | socket |
| With protective conductor: | no |
| Pitch of the contacts: | 5.08 mm |
| Material of the insulating body: | other |
| Material of the contact: | copper |
Features
HAB
FKC 2.5/12-STF-5.08 BD:1-12Q/3
Minimal order
1000 pcs
Manufacturer
HAN
1187078
GTIN
4063151229436
Connectable conductor cross-section solid
0.2 to 2.5 mm²
Rated current In
12A
Flammability class of the insulating material according to UL 94
V0
Housing color
Green
