Rademacher 22601056 CLIM 10/16PZ C-line Medium 10 Nm tubular motor RolloTube

The RolloTube C-line Medium (CLIM 10/16PZ) is a self-learning tubular motor with a soft stop. Thanks to Plug & Play, it can be installed in a particularly time- and cost-saving manner, as the tubular motor does not require any learning of the end points or a learning run. All that is required for self-learning are rigid shaft connectors and stoppers or a stopper bar. Alternatively, the end points can also be set manually using the set button and supply line. The motor has precise position detection and torque monitoring and protects the curtain from damage in both directions thanks to integrated blockage detection. The motor can also be connected in parallel and has a lockable universal motor head, which enables installation without tools and ensures high compatibility with other systems. The RolloTube C-line has a plug-in cable and is supplied with a PVC connection cable with a length of 2.5 m. Additional connection cables (5 m/10 m) are available as accessories. It is pre-adapted for an octagonal steel shaft with a wrench size of 60. With the available accessories, it can also be adapted for octagonal steel shafts with wrench sizes of 50 and 70, round shafts with a diameter of 50, 60, 63 and 70 mm, grooved tubes with a flat groove with a diameter of 63 mm, grooved tubes with a flat/round/MHZ groove with a diameter of 70 and 78 mm, grooved tubes with a flat/round groove with a diameter of 85 mm, Siral shafts with a diameter of 50 mm and the Eckermann profile shaft with a diameter of 65 mm. The torque is 10 Nm and the speed is 16 rpm. The RADEMACHER motor comes with a 5-year guarantee.
