Powder-coated sheet steel housing, rectangular cross-section, with sturdy steel front sides, housing back with integrated pull-in nuts for attaching the accessories for ceiling mounting and chain suspension from the outside. Direct, deep-wide beam light distribution using individual lens. Optic made of PMMA plastic. Driver integrated. Electrical connection via 2.3 m long connecting cable 3x1.0 mm.
| Property | Value |
| Max. System power: | 98 W |
| Rated luminous flux according to IEC 62722-2-1: | 14600 lm |
| Protection class: | I |
| Impact resistance: | IK03 |
| Protection class (IP): | IP54 |
| Housing color: | white |
| Color temperature: | 4000 K |
| Suitable for number of bulbs: | 1 |
| Bulb: | LED not replaceable |
| Length: | 688 mm |
| Width: | 340 mm |
| Height/Depth: | 59 mm |
| Socket: | without |
| With light source: | yes |
| Operating device: | LED operating device, current-controlled |
| Nominal voltage: | 230 V |
| Beam angle: | medium beam 21-40° |
| DALI dimming: | no |
| Light color: | white |
| With operating device: | yes |
| Voltage type: | AC |
| Suitable for emergency lighting: | no |
| Material of the housing: | steel |
| Mounting type: | pendulum |
| With protective cover: | no |
| Material of the reflector: | without reflector |
| Reflector: | without |
| Ball-proof: | no |
| Luminaire with limited surface temperature 'D-mark': | yes |
| Color rendering index CRI: | 80-89 |
| Light distribution: | symmetrical |
| Suitable for secondary lamps: | no |
| Dimming 0-10 V: | no |
| Dimming 1-10 V: | no |
| Dimming DMX: | no |
| Dimming DSI: | no |
| Dimming trailing edge: | no |
| Dimming leading edge: | no |
| Dimming potentiometer (integrated in device): | no |
| Dimming GPRS: | no |
| Dimming LineSwitch: | no |
| Dimming manufacturer-specific: | no |
| Dimming mains voltage modulation: | no |
| Dimming programmable: | no |
| Dimming RF: | no |
| Dimming Sine Wave Reduction: | no |
| Dimming Touch and Dim: | no |
| Dimming Zigbee: | no |
| Dimming with Push button: | no |
| Without dimming function: | yes |
| Light distributor: | Focus lens |
| Protection class (NEMA): | other |
| Glow wire test according to IEC 60695-2-11: | without |
| Rated ambient temperature according to IEC62722-2-1: | -20 to 45 °C |
| Suitable for lamp power: | 98 W |
| Type of wiring: | Termination |
| Number of poles: | 3 |
| Connection type: | other |
Features
HAB
Worker-WOHTB/0700 IP54 14800lm 840
Manufacturer
HAN
37440124130
GTIN
4020863338757
Connection type
Other
Type of wiring
Diploma
Beam angle
Medium beam 21-40°
Rated luminous flux according to IEC 62722-2-1
14600lm
Rated ambient temperature according to IEC62722-2-1
-20 to 45 °C
Operating device
LED control gear current controlled
Width
340 mm
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming mains voltage modulation
No
Dimming trailing edge
No
Dimming phase control
No
Dimming potentiometer (integrated)
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming manufacturer-specific
No
Dimming with push button
No
Dimming programmable
No
Color temperature
4000K
Color rendering index CRI
80-89
Version
Without
Suitable for lamp power
98W
Suitable for number of lamps
1
Suitable for emergency lighting
No
Housing color
White
Glow wire test according to IEC 60695-2-11
Without
Height/Depth
59 mm
Luminaire with limited surface temperature D-mark
Yes
Lamps
LED not replaceable
Light color
White
Light distributor
Focus lens
Light distribution
Symmetrical
Length
688 mm
Max. system performance
98W
With operating device
Yes
With light source
Yes
With protective cover
No
Mounting type
Pendulum
Nominal voltage
230V
Without dimming function
Yes
Number of poles
3
Reflector
Without
Impact resistance
IK03
IP protection)
IP54
Protection class (NEMA)
Other
Protection class
I
Voltage type
AC
Housing material
Steel
