Thanks to the DKN fitting (pressure-tilt glass only), the light can be opened without tools when changing the lamp. Fitting not visible. Easy to install. Problem-free application. Timeless design. Bracket: galvanized metal. Cover attached using tilt springs (DKN system). Cover: opal glass, satin finish, hand-blown. Energy efficiency class A+
| Property | Value |
| Max. System power: | 6 W |
| Rated luminous flux according to IEC 62722-2-1: | 500 lm |
| Suitable for number of lamps: | 1 |
| Height/depth: | 105 mm |
| Protection rating (IP): | IP40 |
| Protection class: | I |
| Luminaire with limited surface temperature 'D-mark': | no |
| Nominal voltage: | 220 to 240 V |
| Housing color: | white |
| Housing material: | steel |
| Color temperature: | 4000 K |
| Impact resistance: | IK02 |
| Color rendering index CRI: | 80-89 |
| Suitable for ceiling mounting: | yes |
| Suitable for wall mounting: | yes |
| Outer diameter: | 250 mm |
| Voltage type: | AC |
| With motion detector: | no |
| Beam angle: | extremely wide beam >80° |
| With light source: | yes |
| Light source: | LED not replaceable |
| Rated ambient temperature according to IEC62722-2-1: | 25 °C |
| Socket: | other |
| Connection type: | screw terminal |
| With operating device: | no |
| Cover material: | opal glass |
| Light distributor: | without |
| Without dimming function: | yes |
| Light emission: | direct/indirect |
| Light distribution: | symmetrical |
| With Light sensor: | no |
| Operating device: | not required |
| Suitable for recessed mounting: | no |
| Light color: | white |
| Suitable for computer workstations in accordance with EN 12464-1: | yes |
| Suitable for light strip configuration: | no |
| Suitable for pendulum suspension: | no |
| Suitable for surface mounting: | yes |
| Suitable for emergency lighting: | no |
| Design of the grid: | without |
| Covering of the lamp with thermal insulation material possible: | yes |
| DMX dimming: | no |
| DSI dimming: | no |
| With air slots: | no |
| LineSwitch dimming: | no |
| Potentiometer dimming (device integrated): | no |
| Dimming 0-10 V: | no |
| Dimming GPRS: | no |
| Dimming 1-10 V: | no |
| Dimming manufacturer-specific: | no |
| Dimming DALI: | no |
| Dimming mains voltage modulation: | no |
| Dimming phase control: | no |
| Dimming phase control: | no |
| Dimming programmable: | no |
| Dimming RF: | no |
| Dimming Sine Wave Reduction: | no |
| Dimming Touch and Dim: | no |
| Dimming Zigbee: | no |
| Dimming with push button: | no |
| Dimming dependent from the operating device: | no |
| Protection class (NEMA): | other |
| Glow wire test according to IEC 60695-2-11: | 960 °C - 30 s |
| Suitable for lamp power: | 6 W |
| Luminaire luminous efficacy: | 84 lm/W |
| Type of wiring: | suitable for through wiring |
| Number of poles: | 3 |
| Conductor cross section: | 2.50 mm² |
Features
HAB
9,1W 4000K D250 H105 DKN white
Manufacturer
HAN
10122.002
GTIN
4051859069218
Covering the luminaire with thermal insulation material possible
Yes
Connection type
Screw terminal
Type of wiring
Suitable for through wiring
Execution of the grid
Without
Outer diameter
250 mm
Rated luminous flux according to IEC 62722-2-1
500lm
Rated ambient temperature according to IEC62722-2-1
25°C
Operating device
Not required
Suitable for computer workstations according to EN 12464-1
Yes
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming mains voltage modulation
No
Dimming trailing edge
No
Dimming phase control
No
Dimming potentiometer (integrated)
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming depends on the control gear
No
Dimming manufacturer-specific
No
Dimming with push button
No
Dimming programmable
No
Color temperature
4000K
Color rendering index CRI
80-89
Version
Other
Suitable for surface mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for flush mounting
No
Suitable for lamp power
6W
Suitable for number of lamps
1
Suitable for light strip configuration
No
Suitable for emergency lighting
No
Suitable for pendulum suspension
No
Suitable for wall mounting
Yes
Housing color
White
Glow wire test according to IEC 60695-2-11
960 °C - 30 s
Height/Depth
105 mm
Conductor cross-section
2.50 mm²
Luminaire with limited surface temperature D-mark
No
Luminaire luminous efficacy
84lm/W
Lamps
LED not replaceable
Light emission
Direct/indirect
Light color
White
Light distributor
Without
Light distribution
Symmetrical
Max. system performance
6W
With operating device
No
With motion detector
No
With light source
Yes
With light sensor
No
With air slots
No
Nominal voltage
220 to 240 V
Without dimming function
Yes
Number of poles
3
Impact resistance
IK02
IP protection)
IP40
Protection class (NEMA)
Other
Protection class
I
Voltage type
AC
Cover material
Glass opal
Housing material
Steel
