The flat design offers universal usability thanks to the choice of round or square glass cover. The cover made of crystal glass with a frosted interior also shines in daylight. Use of smart, cost-effective LED modules for mains voltage with high LED system light output for energy-saving operation. Durability through the use of high-quality materials such as aluminum, crystal glass and a durable powder coating. Fastening points outside the lamp compartment, safe installation through consistent error avoidance. Seawater-resistant coating. Fast installation: tolerance compensation for drill holes. Generous cable routing space allows wall outlet even in the middle of the luminaire. Electrical connection via plug-in terminals. Diffuser fastening using mounting fixation. Second cable entry for mains forwarding. The high protection class IP 65 allows maintenance-free, problem-free LED operation. Also available as a version for emergency lighting. Housing made of corrosion-resistant die-cast aluminum for outdoor use, powder-coated. Cover made of crystal glass with a frosted interior. Screwless installation of the cover with a snap lock. Fastening outside the sealed area with hole tolerance compensation. Light source (mains voltage LED module) included in delivery. With diaphragm valve as standard to prevent condensation. With second cable entry for mains forwarding. Light with motion detector including twilight switch. Energy efficiency class A+, A+A+
| Property | Value |
| Max. System power: | 12 W |
| Rated luminous flux according to IEC 62722-2-1: | 630 lm |
| Suitable for number of lamps: | 1 |
| Length: | 257 mm |
| Width: | 257 mm |
| Height/depth: | 81 mm |
| Protection rating (IP): | IP65 |
| Protection class: | I |
| Luminaire with limited surface temperature 'D-mark': | no |
| Nominal voltage: | 220 to 240 V |
| Housing color: | Silver |
| Housing material: | Aluminum |
| Color temperature: | 3000 K |
| Impact resistance: | IK05 |
| Color rendering index CRI: | 80-89 |
| Suitable for ceiling mounting: | yes |
| Rated service life L80/B10 at 25 °C: | 50000 h |
| Suitable for wall mounting: | yes |
| Voltage type: | AC |
| With motion detector: | yes |
| Beam angle: | extremely wide beam >80° |
| With light source: | yes |
| Light source: | LED not replaceable |
| Rated ambient temperature according to IEC62722-2-1: | -20 to 41 °C |
| Socket: | other |
| Connection type: | Plug-in terminal |
| With operating device: | yes |
| Cover material: | Opal glass |
| Light distributor: | without |
| Without dimming function: | yes |
| Light emission: | direct |
| Light distribution: | symmetrical |
| With light sensor: | yes |
| Operating device: | LED operating device, current-controlled |
| Suitable for recessed mounting: | no |
| Light color: | white |
| Suitable for computer workstations in accordance with EN 12464-1: | no |
| Suitable for light strip configuration: | no |
| Suitable for pendant suspension: | no |
| Suitable for surface mounting: | yes |
| Suitable for emergency lighting: | no |
| Design of the grid: | without |
| Covering of the luminaire with thermal insulation material possible: | yes |
| DMX dimming: | no |
| DSI dimming: | no |
| With air slots: | no |
| Dimming LineSwitch: | no |
| Dimming potentiometer (device integrated): | no |
| Dimming 0-10 V: | no |
| Dimming GPRS: | no |
| Dimming 1-10 V: | no |
| Dimming manufacturer-specific: | no |
| Dimming DALI: | no |
| Dimming mains voltage modulation: | no |
| Dimming trailing edge: | no |
| Dimming leading edge: | no |
| Dimming programmable: | no |
| Dimming RF: | no |
| Dimming Sine Wave Reduction: | no |
| Dimming Touch and Dim: | no |
| Dimming Zigbee: | no |
| Dimming with push button: | no |
| Dimming depending on the operating device: | no |
| Protection class (NEMA): | other |
| Glow wire test according to IEC 60695-2-11: | 960 °C - 30 s |
| Suitable for lamp power: | 12 W |
| Luminous efficacy: | 53 lm/W |
| Type of Wiring: | suitable for through wiring |
| Number of poles: | 3 |
| Conductor cross-section: | 2.50 mm² |
