Load-disconnector Compact INS. 3-pole, 800A, cast-encapsulated. Complete device in fixed installation, version with red rotary drive and yellow front. Compact INS/INV switch disconnectors are designed for switching and isolating electrical distribution circuits in the service sector and industrial areas.
| Feature | Value |
| Number of poles: | 3.0 |
| Operating power: | 400.0 kW |
| Number of auxiliary contacts as normally closed contacts: | 0.0 |
| Number of auxiliary contacts as normally open contacts: | 0.0 |
| Number of auxiliary contacts as changeover contacts: | 4.0 |
| Rated continuous current Iu: | 800.0 A |
| Max. Rated operating voltage Ue at AC: | 690.0 V |
| Design as EMERGENCY STOP device: | yes |
| Protection class (IP), front: | IP40 |
| Connection type main circuit: | Screw connection |
| Device design: | Built-in device, fixed installation technology |
| Design of the actuating element: | long rotary handle |
| Suitable for floor mounting: | yes |
| Integrated motor drive: | no |
| Suitable for front mounting 4-hole: | yes |
| Version as maintenance/repair switch: | yes |
| Voltage release optional: | no |
| Suitable for front mounting central: | yes |
| Suitable for intermediate installation: | no |
| Suitable for distribution board installation: | yes |
| Version as main switch: | yes |
| Version as a safety switch: | no |
| Motor drive optional: | no |
| Lockable: | yes |
| Version as a reversing switch: | no |
| Rated short-time withstand current Icw: | 50.0 kA |
| Color of the actuating element: | red |
| Rated operating voltage: | 0.0 to 690.0 V |
| Rated continuous current at AC-21, 400 V: | 800.0 A |
| Number of switches: | 1.0 |
| Rated continuous current at AC-23, 400 V: | 800.0 A |
Features
Number of auxiliary contacts as changeover contacts
4.0
HAB
31344 Interpact INS800 3P red rotary drive.
Manufacturer
HAN
31344
GTIN
3303430313441
Connection type main circuit
Screw connection
Number of auxiliary contacts as normally open
0.0
Number of auxiliary contacts as normally closed
0.0
Number of switches
1.0
Designed as main switch
Yes
Designed as an EMERGENCY STOP device
Yes
Designed as a safety switch
No
Designed as a maintenance/repair switch
Yes
Version as reversing switch
No
Design of the actuating element
Long rotary handle
Rated operating voltage
0.0 to 690.0V
Rated continuous current Iu
800.0A
Rated continuous current at AC-21, 400 V
800.0A
Rated continuous current at AC-23, 400 V
800.0A
Rated short-time withstand current Icw
50.0kA
Color of the actuator
Red
Suitable for floor mounting
Yes
Suitable for front mounting 4-hole
Yes
Suitable for front mounting Central
Yes
Suitable for distribution board installation
Yes
Suitable for intermediate construction
No
Device type
Built-in device Fixed installation technology
Max. rated operating voltage Ue at AC
690.0V
Motor drive integrated
No
Motor drive optional
No
Number of poles
3.0
Protection class (IP), front
IP40
Voltage release optional
No
Lockable
Yes
