Floor-mounted socket, 32A, 2p, 20-25 V AC, IP44
| Property | Value |
| IEC current: | 32.0 A |
| Number of poles: | 2.0 |
| Connection technology: | screw terminal |
| Plug direction: | straight |
| Voltage according to EN 60309-2: | 20-25 V (50+60 Hz) violet |
| Identification color: | violet |
| Protection class (IP): | IP44 |
| Material: | plastic |
| Military version: | no |
| Horizontal hole spacing: | 77.0 mm |
| Horizontal flange dimension: | 65.0 mm |
| Vertical flange dimension: | 65.0 mm |
| RAL number: | 7035.0 |
| Rated voltage: | 20.0 to 25.0 V |
| Rated frequency: | 50.0 to 60.0 Hz |
Features
Rated frequency
50.0 to 60.0 Hz
HAB
82915
Manufacturer
HAN
82915
GTIN
3303430829157
Connection technology
Screw terminal
Rated voltage
20.0 to 25.0V
IEC current
32.0A
Identification color
Violet
Military version
No
Number of poles
2.0
RAL number
7035.0
IP protection)
IP44
Voltage according to EN 60309-2
20-25 V (50+60 Hz) violet
Plug direction
Straight
Material
Plastic
